WE-D Series Digital ISO DIN ASTM Universal 100ton Hydraulic Pressure Testing Machine
1. Application
Steel Rebar ISO DIN ASTM Universal Tensile Testing Machine Is suitable for doing
testing experiments such as the tensile, compression, bending and sheartesting for all kinds of metal materials and nonmetal materials such as plastic, concrete, cement and so on.
2. Standards
ISO75001, ASTM A370, ASTM E4, ASTM E8 and BSEN standards
3. Features
3.1 Specially designed extra-thick jaws block,sample clamp more reliable
3.2 Wear-resistant lining,protect jaws block
3.3 Fast operation testing system,multi specimen information imput
3.4 Consistant resolution,make sure data accuracy
3.5 Testing data real time display
3.6 Testing data auto analysis,save and print
3.7 Overload protection
3.8 History record check function
3.9 Software reserved data interface
4. Main Specifications
Model |
WE- 100D |
WE- 300D |
WE- 600D |
WE- 1000D |
WE- 2000D |
||||
Max load (kN) |
100 |
300 |
600 |
1000 |
2000 |
||||
Structure |
Six columns chain transmission oil cylinder underneath type |
||||||||
Control way |
Manual control loading process |
||||||||
Test class |
1 class ( 0.5 class optional ) |
||||||||
Test range(FS) |
2%-100% (0.4%-100% optional ) |
||||||||
Test value error(%) |
≤±1% ( ≤± 0.5% optional ) |
||||||||
Force resolution |
0.01kN |
||||||||
Deformation effective test range (FS) |
2%~100% |
||||||||
Deformation value relative error(%) |
≤±0.5 |
||||||||
Displacement resolution (mm) |
0.01 |
||||||||
Displacement error(%) |
≤±0.5% |
||||||||
Max piston stroke(mm) |
200 |
250 |
|||||||
Max piston moving speed (mm/min) |
0-70 manual adjust |
||||||||
Beam adjust speed(mm/min) |
270 |
||||||||
Max tensile space (mm) |
650 (can customize) |
900 |
|||||||
Max compression space (mm) |
500 |
450 |
500 |
800 |
|||||
Effective space between columns (mm) |
420 |
470 |
520 |
760 |
|||||
Clamp way |
Manual clamp |
||||||||
Round sample clamp diameter (mm) |
Φ10-Φ32 |
Φ13-Φ40 |
Φ13-Φ50 |
φ15-70 |
|||||
Flat sample clamp thickness(mm) |
0-15 |
0-15mm |
0-30mm |
0-60 |
|||||
Flat sample clamp width (mm) |
75 |
85 |
|||||||
Compression plate size (mm) |
φ160 |
Φ240 |
|||||||
Bending grip |
Three points mode |
||||||||
Bending roller distance (mm) |
450 |
||||||||
Bending roller width (mm) |
120 |
160 |
|||||||
Bending roller upper and lower diameter(mm) |
3×Φ30 |
3×Φ50 |
|||||||
Compression grip (mm) |
Φ160 spherical surface Automatic alignment mode compression grip |
Φ240 |
|||||||
Power supply |
380V/50Hz/three phrase four wire system |
||||||||
