WDW Series 10kn to 600kn Computer Automatic Electronic Universal Tensile Material Testing Equipment Price

WDW Series 10kn to 600kn Computer Automatic Electronic Universal Tensile Material Testing Equipment Price thumbnail-1
WDW Series 10kn to 600kn Computer Automatic Electronic Universal Tensile Material Testing Equipment Price thumbnail-2
WDW Series 10kn to 600kn Computer Automatic Electronic Universal Tensile Material Testing Equipment Price thumbnail-3
WDW Series 10kn to 600kn Computer Automatic Electronic Universal Tensile Material Testing Equipment Price thumbnail-4
WDW Series 10kn to 600kn Computer Automatic Electronic Universal Tensile Material Testing Equipment Price thumbnail-5
WDW Series 10kn to 600kn Computer Automatic Electronic Universal Tensile Material Testing Equipment Price thumbnail-6
WDW Series 10kn to 600kn Computer Automatic Electronic Universal Tensile Material Testing Equipment Price photo-1
WDW Series 10kn to 600kn Computer Automatic Electronic Universal Tensile Material Testing Equipment Price photo-2
WDW Series 10kn to 600kn Computer Automatic Electronic Universal Tensile Material Testing Equipment Price photo-3
WDW Series 10kn to 600kn Computer Automatic Electronic Universal Tensile Material Testing Equipment Price photo-4
WDW Series 10kn to 600kn Computer Automatic Electronic Universal Tensile Material Testing Equipment Price photo-5
WDW Series 10kn to 600kn Computer Automatic Electronic Universal Tensile Material Testing Equipment Price photo-6
US$ 222526.23 1 Set
US$ 207830.64 ≥2 Set
Key Specifications
Get Latest Price
Weight:
650kg
brand name:
HST
place of origin:
Shandong, China
Contact Supplier Request Quote Chat Now
Hst Group Co.,ltd.
Gold Verified Supplier
1Yr
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
brand name HST
place of origin Shandong, China
customized support OEM, ODM
power Electronic
warranty 1 year
model number WDW-600E
Product name Material testing equipment
Max load 500/ 600KN
Standard ASTM ISO EN JS
Dimension 1045*545*1325mm
Test range 2%-100% FS
Function tensile compression, bending,. shear test, etc
Accuracy 1 Grade/0.5 Grade
Power supply 220v, 50/60hz
Tensile space 800mm

WDW Series 10kn to 600kn Computer Automatic Electronic Universal Tensile Material Testing Equipment Price

WDW Series 10kn to 600kn Computer Automatic Electronic Universal Tensile Material Testing Equipment Price



Product Description

Application: Material testing equipment

WDW series Electronic Universal Material Testing Equipment Price is suitable for wide

range of material for tensile, compression, bending, split, cut, torn, punctured, burst, yield strength, elongation, nonproportional strength, modulus of elasticity, and other parameters.



Test Material: Material testing equipment

It is for metal, rubber, plastic, spring, textile, rope, glass and other composite materials testing.

It applies to aerospace industry, engineering inspection, university and college, iron and steel industry, research institution and other fields.Computer automatic control machine rise,

fall, test and stop etc. Easy operation, stable performance.



Technical parameter: Electronic Universal Material Tensile Testing Equipment Price

Model

WDW-20

WDW-30

WDW-50

WDW-100

 WDW-200/ 300

WDW-500/ 600

Max. Load

20kN

30KN

50KN

100kN

 200kN

300kN

500kN

600kN

Structure

Four-column Floor Type (upper is compression and lower is tensile)

Control model

Constant stress, constant strain,constant

displacement closedloop control System

Load accuracy

1 class/ 0.5 class optional

Load range

2%-100% of full scale /0.4%-100% optional

Load resolution

1/300000

Deformation test range

 2%~100%

Deformation accuracy

≤±1%

Displacement accuracy

≤±1%

Disp. resolution

0.04um

Displacement speed

0.05-1000mm/min

0.05-200mm/min

Tensile space

600mm

700mm

550mm

700mm

Compression space

600mm

700mm

550mm

700mm

Test width

400mm

450mm

600mm

650mm

Clamp way

Manual clamp / Hydraulic clamp (optional)

Hydraulic

clamp

Load Cell Configuration

One(max load), more load cells can be added according to

 customer requirement

Extend configuration

Large deformation extensometer, high or low

temperature teste chamber, high temperature oven

Power supply

AC220/380V±10%,50Hz (can be customized)
