Rubber Hose Pipe Electronic Tensile Test 10KN Testing Machine

Rubber Hose Pipe Electronic Tensile Test 10KN Testing Machine thumbnail-1
Rubber Hose Pipe Electronic Tensile Test 10KN Testing Machine thumbnail-2
Rubber Hose Pipe Electronic Tensile Test 10KN Testing Machine thumbnail-3
Rubber Hose Pipe Electronic Tensile Test 10KN Testing Machine thumbnail-4
Rubber Hose Pipe Electronic Tensile Test 10KN Testing Machine thumbnail-5
Rubber Hose Pipe Electronic Tensile Test 10KN Testing Machine thumbnail-6
Rubber Hose Pipe Electronic Tensile Test 10KN Testing Machine photo-1
Rubber Hose Pipe Electronic Tensile Test 10KN Testing Machine photo-2
Rubber Hose Pipe Electronic Tensile Test 10KN Testing Machine photo-3
Rubber Hose Pipe Electronic Tensile Test 10KN Testing Machine photo-4
Rubber Hose Pipe Electronic Tensile Test 10KN Testing Machine photo-5
Rubber Hose Pipe Electronic Tensile Test 10KN Testing Machine photo-6
US$ 600 - 2800 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Testing Machine
brand name:
Hensgrand
place of origin:
Shandong, China
Contact Supplier Request Quote Chat Now
Hst Group Co.,ltd.
Gold Verified Supplier
1Yr
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
brand name Hensgrand
place of origin Shandong, China
Application Tensile Testing, Strength Testing, Paper Testing, Textile Testing, Plastic Testing, Universal Testing, Wood Testing, Bending Testing, Laboratory Testing, Lab Testing, Electrical Testing, Paper, Leather, textile, metal etc.
customized support OEM, ODM, OBM
power 350
Voltage 220 V
warranty 1 Year
model number WDS-10
product name rubber hose pipe electronic tensile test 10KN testing machine
Test force 10KN (10000N)
Load Accuracy ±1% or ±0.5%
resolution of load 1/300000 of full scale
Tensile Test Space 650mm
Grips Manual Grip or Hydraulic Grip
Power supply 220V/380V/110V, 50-60HZ
Certificate CE/ASTM/JIS
resolution of deformation measurement 2%-100%

rubber hose pipe electronic tensile test 10KN testing machine

Rubber Hose Pipe Electronic Tensile test 10KN Testing MachineRubber Hose Pipe Electronic Tensile test 10KN Testing MachineRubber Hose Pipe Electronic Tensile test 10KN Testing Machine

Product Description

 WDS series digital display electronic universal testing machines and WDW computer control universal testing machines are designed and manufactured according to ASTM, ISO, DIN, GB and other international standards.



Applicable for wide range of material for tension, compression, bending, shearing and low cycle test. Suitable for metal, rubber, plastic, spring, textile, and components testing. It is widely used in the corresponding industries, research and development, test institutes and training centers etc.

Specification Data

  Digital display control universal Testing machine specification :

Model

WDS-02, WDS-05,

WDS-1, WDS-5

WDS-10

WDS-20

WDS-50

WDS-100

WDS-200

WDS-300

Max. Load (KN)



0.2 or 0.5

1 or 5

10 or 20

50 or 100

200 or 300

Control Method



Single Chip Control

Load Accuracy



±1%

Load Range



2%~100% of Full Scale

Relative Error of Reading



≤±0.5%

Relative Error of Speed



≤±1%

Resolution of Displacement



0.01mm

Control Speed (mm/min)

0.005-500(mm/min)

0.005-200

(mm/min)

Tensile Test Space



650mm

Compression Test Space



650mm

Grips



Manual Grip or Hydraulic Automatic Grip (Optional)

Power Supply



AC110V / 220V / 380V±10%, 50HZ-60HZ
