Home > Construction & Decoration > Pipe Fittings > Tee > ASTM A105 Hot Dip Galvanised Forged Pipeline Fitting Socket Weld Elbow Carbon Steel
ASTM A105 Hot Dip Galvanised Forged Pipeline Fitting Socket Weld Elbow Carbon Steel
Negotiable
MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
FLRS
Place of Origin:
China
Model Number:
FLRS-T010
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang or Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
A182 F304L 316L Socked Welding Type Forged Full Coupling Stainless Steel Class 3000NegotiableMOQ: 5 Pieces -
Carbon Steel Pipe Fitting Threaded Union A105 MSS SP83NegotiableMOQ: 5 Pieces
-
Class 6000 Socket Welding Forged Half Stainless Steel Coupling A182 F304L 316LNegotiableMOQ: 5 Pieces
-
Class 3000 Forged Steel Pipe Fitting 90 Degree Elbow A182 F316L ASME B16.11NegotiableMOQ: 5 Pieces
-
Socket Weld 45 Degree Elbow Forged Pipeline Fitting Stainless Steel A182 F304 F316NegotiableMOQ: 5 Pieces
Brand Name
FLRS
Place of Origin
China
Model Number
FLRS-T010
Material
Carbon Steel
Type
Elbow
Shape
Equal
Technics
Forged
Connection
Welding
Head Code
Other, Round
| Product Name: | 45-deg Elbow | Standard: | ASME B16.11 |
|---|---|---|---|
| Pressure Rating: | 2000LB-9000LB | Material: | A105 |
| Connection Type: | Socket Weld | Size: | 1/8"-4" |
| Surface Treatment: | H.D.G Or Black | Package: | Carton |
| High Light: | Socket Weld 45 Degree Elbow, Hot Dip Galvanised Socket Weld Elbow, Carbon Steel Forged Pipe Fittings Elbow | ||
Forged pipeline Fitting Carbon Steel Material ASTM A105 Socket Weld 45-deg Elbow Hot Dip Galvanised
| PIPE FITTINGS | |
Product Name | 45-deg Elbow |
| Size Range | 1/8"-4" |
| Technology | Forging |
| Connection Type | Socket-Weld |
| Pressure Range | 2000LB-9000LB |
Hot dipped galvanized socket weld elbow dimensions is from 1/8” to 4”, class 2000, class 3000, class 6000 and class 9000. Socket weld fittings have exceptional strength of welded joints. Hot dip galvanizing is a prevalent coating for carbon steel forged fittings because the coating is even and thicker than cold galvanizing and has better corrosion resistance.
| Dimensions | ASME 16.11, MSS SP-79, MSS SP-95, 83, 95, 97, BS 3799 |
| Size | 1/8″~4″ (DN6~DN100) |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Type | Socket Weld (S/W) & SCREWED (SCRD) – NPT, BSP, BSPT |
| Form | 90 Deg Threaded Elbow, Threaded Elbow, Threaded Pipe elbow |
| Value Added Services: | Hot Dipped Galvanizing, Epoxy & FBE Coating, Electro Polish, Sand Blasting, Threading, Soldering |
| Production Grades: | Stainless Steel, Alloy Steel, Duplex, Nickel Alloys, Low temperature Steel, Carbon Steel, Cupro Nickel |
