Security cable 4/6/8 core fire alarm cable with LSZH FR-PVC red jacket copper wire

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Fire Alarm Cables

Working Principle:
The fire detector turns into an electric signal, which is transmitted to the fire alarm controller, and at the same time informs the evacuation of the entire floor in the form of sound or light. The controller records the location and time of the fire.

Application:

Widely used in various alarm systems, fire protection systems, anti-theft systems, smoke and dust control systems, and other communication systems.

Fire Alarm cable

. 1.5mm2*4c Bare Copper

. FR-PVC

. Shield: Al Foil

. Jacket: SR-PVC

. Color: Red/Customized

. Packaging Type: 100m roll/OEM

. Operating Voltage: 300V

. OEM is available

Characteristics
Normal aera (mm²)	Structure (mm)	Insulated thickness (mm)	Braid thickness (mm)	Overall dia. (mm)
0.5	20/0.18	0.50	0.15	2.25
0.5		16/0.20	0.50	0.15	2.25
0.75	30/0.18	0.50	0.15	2.45
0.75		24/0.20	0.50	0.15	2.45
1.0	40/0.18	0.50	0.15	2.65
1.0		32/0.20	0.50	0.15	2.65
1.50	48/0.20	0.60	0.15	3.10
1.50		30/0.25	0.60	0.15	3.10
2.50	80/0.20	0.70	0.15	3.75
2.50		49/0.25	0.70	0.15	3.75

Features:

1. High-purity oxygen-free copper, stable transmission, low loss, excellent fire resistance, and safety use.

2. The product apply to:*NEC: 725 & 760
*UL Standard: UL 13 & UL 1424 & UL 444
*Flame Rating: UL 1666 Riser c(UL) FT4
*RoHS: Compliant Directive 2011/65/EU
This cable complies with VW – 1 Flame Test requirements.

* Are you a manufacture or a trading company?

Sanyuan cable Company is a professional cable manufacturer with 23 years production experience.

* Whether these products quality assures?

Most of cables are certificated. Also, we have strict QC,all products are 100% tested before delivery.Quality is assured.

* When I want customized products,how to do?

We have Equipped with professional equipment,technicians & skilled employees, OEM & Customized service is welcome.Drawing/Samples are required.

* Can you send a sample for us to test?

1, If we have inventory and total amount is small,it's free.

2, If we don't have inventory,sample and freight cost have to be paid by your esteemed company.But we will return the sample cost to you when we receiving your initial order.

* If I want to purchase,how to pay?

Generally we do T/T in 30% deposit before production,70% balance against copy of B/L.Also payment terms are negotiable depending on customer's request.

* After I pay,what about the lead time and shipping method?

Goods can be delivered by air,by express or by sea;International Express as FedEx,UPS,DHL,TNT;You can choose the best the best way as you wish.As for the Lead time,10~20 days.
