GSM/GPRS Module MG301 B2B Board to Board to Replace MG323

FOB Price

Negotiable

1 (Min. Order)

Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

Description

GSM/GPRS Module MG301 B2B (the replacement for MG323)

Physical property

Dimensions: 24 mm*24 mm*2.95 mm (MG301)
Weight: < 3g

Operating Frequency Band

Support Frequency Band GSM 4: GSM/GPRS: 850MHz/ 900 MHz/ 1800MHz/ 1900MHz

Operating Temperature

Normal : -20℃ ~ +70℃
Limit : -20℃ ~ +70℃

Storage Temperature

-40℃ ~ +85℃

Voltage

DC 3.3 V ~ 4.2 V (typical value: 3.8 V)

AT Command

Please refer to <MG301 GSM LCC Module AT Command Manual>

Consumption (test under 3.8 V)

Shutdown leakage current : 240µA

Dormancy average current : < 3.0mA

GPRS class 10 (Max.): l typical= 350mA

Application interface (68-pin LCC Interfaces)

SIM Card Interface (3.0V & 1.8V)

2 Channels Analog Sound Interface

UART1 Interface (support 8 serial lines) & UART0 Interface (support 2 serial lines)

USB Interface

Network status indicator

Interface Switch

Hardware reset interface

Hibernates/Wakes up control Interface

Sleep State Indicator Interface

Wake up host interface

Antenna Interface

Solder Pad

SMS

Support SMS alerts, text messages and send messages
Support SMS management: Read/Delete SMS, saving state, message list
Support PDU mode

GPRS

GPRS CLASS 10
Encoding: CS 1, CS 2, CS 3, CS 4
Max. Downlink transmission rate: 85.6 kbit/s
Max. Uplink transmission rate: 42.8 kbit/s
Support PBCCH
Built-in TCP/IP protocol, support several Socket to link

Why Choose Us

FAQ

Q1. What is the minimum order quantity for your products? A1. Minimum order quantity starts from ONE piece. Q2. What's the quality of your products? A2. We have professional QA/QC team to ensure the quality before shipment. We provide 1 year warranty for all the new and original products. Q3. Is this product free of shipping or free samples? A3. Regularly the sample and shipping cost will be at the buyer's account. But in specific case, we may take these costs. Please kindly check with us the details by email. Thank you.
