Low Power G7020 Chip Set GT-1612-UB7X GPS Module
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1999
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
150/50Mbps A7600C-L1 4G LTE Cat4 Module A7600 A7600CNegotiableMOQ: 1 -
10Mbps/5Mbps 4G Cat1 LTE/GSM/GPRS/EDGE Module A7672E A7672NegotiableMOQ: 1
-
850/900/1800/1900MHz Quad Band GSM 4G Cat1 LTE/GSM/GPRS/EDGE Module A7672 A7672SANegotiableMOQ: 1
-
LCC+LGA Form Factor 10Mbps/5Mbps 4G LTE Cat 1 Module A7672 A7672SNegotiableMOQ: 1
-
A7682E LTE Cat 1 Module LCC+LGA Form Factor 4G RF Module A7682NegotiableMOQ: 1
Description
General Description
• The Gotop GT-1612-UB7X is a complete GPS engine module that features super sensitivity, ultra low power and small form factor.
• The GPS signal is applied to the antenna input of module, and a complete serial data message with position, velocity and time information is presented at the serial interface with NMEA protocol or custom protocol.Its –165dBm tracking sensitivity extends positioning coverage into place like urban canyons and dense foliage environment where the GPS was not possible before.
• The small form factor and low power consumption make the module easy to integrate into portable device like PNDs, mobile phones, cameras and vehicle navigation systems.
Applications
• LBS (Location Based Service)
• PND (Portable Navigation Device)
• Vehicle navigation system
• Mobile phone
Features
• Build on high performance, low-power ublox G7020 chip set
• Ultra high Track sensitivity: -165dBm
• Built in high gain LNA
• Perfect compatibility ublox NEO-7Q/M
• Extremely fast TTFF at low signal level
• Low power consumption: Max 35mA@3.3V
• NMEA-0183 compliant protocol or custom protocol
• Operating voltage: 2.8V to 3.6V
• Operating temperature range:-40to85℃
• SMD type with stamp holes
• Small form factor: 16x12.2x2.6mm
• RoHS compliant (Lead-free)
