Product Description
Description
SIM7906E-PCIE
SIM7906E-PCIE is the LTE Cat 6 module which supports wireless communication modes of LTE-TDD/LTE-FDD/HSPA+. It supports maximum 300Mbps downlink rate and 50Mbps uplink rate.
SIM7906E-PCIE adopts Mini PCIe form factor. It is easy for customers to integrate.
SIM7906E-PCIE integrates multiple satellite high accuracy positioning GNSS systems, with multiple built-in network protocols, supports drivers for main operation systems (USB driver for Windows, Linux and Android etc.) and software function, AT commands are compatible with SIM7500/SIM7600 series modules. Meanwhile SIM7906E-PCIE integrates main industrial standard interfaces, with powerful expansibility, including abundant interfaces such as UART, USB, GPIO, which is suitable for main IoT applications such as telematics, surveillance devices, CPE, industrial routers, and remote diagnostics etc.
Product Advantages
• Mini PCIe interface with strong compatibility
• Suitable for LTE, HSPA+ networks with global coverage
• Abundant software functions: FOTA, SSL, TLS
• Multi-constellation GNSS receiver support
• AT commands of SIM7906E-PCIE are compatible with the SIM7500/SIM7600 series modules
General Features | Other Features |
Frequency Bands: LTE-FDD B1/B3/B5/B7/B8/B20/B28/B32 LTE-TDD B38/B39/B40/B41 DL 2CA B1+B1/B5/B8/B20/B28; B3+B3/B5/B7/B8/B20/B28; B7+B5/B7/B8/B20/B28; B20+B32; B38+B38; B39+B39; B40+B40; B41+B41; (Note:B32 is only for secondary component carrier) WCDMA B1/B3/B5/B8 Supply voltage range: 3.1V ~ 4.4V, Typ. 3.3V Control Via AT Commands Operation temperature:-30℃ ~ +70℃ Dimensions:30.0*51.0*4.3mm Weight:6g±0.2g | USB Driver for Microsoft Windows 2000/XP/Vista/Win7/Win8/Win10 USB Driver for Linux /Android RIL supporting for Android 6/7/8/9 Firmware update via USB TCP/IP/IPV4/IPV6/Multi-PDP/FTP/FTPS /HTTP/HTTPS/DNS* SSL3.0/TLS1.0/TLS1.2 FOTA* |
Certifications | Data |
3C*/SRRC*/NAL*/CE* RoHS*/REACH* | LTE: Uplink 50Mbps Downlink 300Mbps HSPA+: Uplink 5.76Mbps Downlink 42Mbps |
Interfaces | |
USB *1 UART *1 SIM card *1 PCIE *1 PCM *1 I2C *1 Antenna *3 |
