BG95-M3-LA LTE Module BG95M3 BG95M3LA Module BG95-M3

BG95-M3-LA LTE Module BG95M3 BG95M3LA Module BG95-M3 thumbnail-1
BG95-M3-LA LTE Module BG95M3 BG95M3LA Module BG95-M3 thumbnail-2
BG95-M3-LA LTE Module BG95M3 BG95M3LA Module BG95-M3 photo-1
BG95-M3-LA LTE Module BG95M3 BG95M3LA Module BG95-M3 photo-2
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1999
Annual Export Value:
US$50 Million - US$100 Million
Contact Supplier Request Quote Chat Now
Shenzhen Hurryup Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Description
LTE BG95 Cat M1/ Cat NB2/ EGPRS Module

Overview BG95 is a series of multi-mode LPWA modules supporting LTE Cat M1/Cat NB2/EGPRS and integrated GNSS. It is 3GPP Rel-14 compliant and offers maximum data rates of 588 kbps downlink and 1119 kbps uplink under LTE Cat M1. It features ultra-low power consumption by leveraging the integrated RAM/flash as well as the ARM Cortex A7 processor supporting ThreadX, achieving up to 70% reduction in PSM leakage and 85% reduction in eDRX current consumption compared to its predecessor. BG95 boasts a comprehensive set of hardware-based security features and enables trusted applications to run directly on the Cortex A7 TrustZone engine. Additionally, BG95 provides pin-to-pin compatibility with LTE Cat 4 modules EG91/EG95, LTE Cat M1/Cat NB1/EGPRS module BG96, NB-IoT module BC95, UMTS/HSPA modules UG95/UG96 and GSM/GPRS module M95. With a cost-effective SMT form factor of 23.6 mm × 19.9 mm × 2.2 mm and high integration level, BG95 enables integrators and developers to easily design their applications and take advantage from the module's low power consumption and mechanical intensity. Its advanced LGA package allows fully automated manufacturing for high-volume applications. A rich set of Internet protocols, industry-standard interfaces and abundant functions extend the applicability of the module to a wide range of M2M applications such as wireless POS, smart metering, tracking, wearable devices, etc. Key Features ● LTE Cat M1/Cat NB2/EGPRS module with ultra-low power consumption ● Easy migration from GSM/GPRS, UMTS/HSPA and LTE modules ● Integrated RAM and flash in the baseband chipset ● Comprehensive set of hardware-based security features ●Support VoLTE* (Cat M1 only), CS voice* for GSM, QuecOpen®, eSIM, etc. ● Fast time-to-market: reference designs, evaluation tools and timely technical support minimize design-in time and development efforts ● Compact SMT form factor ideal for size-constrained applications with tight space ● Robust mounting and interfaces
LPWA Module
BG95-M1
BG95-M2
BG95-M3
BG95-N1
Region/Operator
For the Global
For the Global
For the Global
For the Global
LTE FDD
Cat M1 Only:
B1/B2/B3/B4/B5/B8/
12/B13/B18/B19/
B20/B25/B26/B27/B28/
B66/B85
Cat M1:
B1/B2/B3/B4/B5/B8/
B12/B13/B18/B19/
B20/B25/B26/B27/B28/
B66/B85
Cat NB2:
B1/B2/B3/B4/B5/B8/
B12/B13/B18/B19/B20/
B25/B28/B66/B71/B85
Cat M1:
B1/B2/B3/B4/B5/B8/
B12/B13/B18/B19/
B20/B25/B26/B27/B28/
B66/B85
Cat NB2:
B1/B2/B3/B4/B5/B8/
B12/B13/B18/B19/B20/
B25/B28/B66/B71/B85
Cat NB2 Only:
B1/B2/B3/B4/B5/B8/
B12/B13/B18/B19/B20/
B25/B28/B66/B71/B85
GSM/EDGE
/
/
850/900/1800/1900 MHz
/
GNSS (Optional)
GPS/GLONASS/BeiDou/
Galileo/QZSS
GPS/GLONASS/BeiDou/
Galileo/QZSS
GPS/GLONASS/BeiDou/
Galileo/QZSS
GPS/GLONASS/BeiDou/
Galileo/QZSS
Wi-Fi (For Positioning)
/
/
/
/
Certification
Carrier:
America:
Verizon/AT&T/
Sprint
Regulatory:
Global: GCF
Europe: CE
North America:
PTCRB
America: FCC
Canada: IC
Japan: JATE*/TELEC*
Australia/New Zealand:
RCM
Others:
RoHS
Carrier:
Europe:
Vodafone*/
Deutsche Telekom*/
Telefónica*
America:
Verizon/AT&T/Sprint/
T-Mobile*
Canada:
Rogers*/Telus*
China:
China Telecom*/
China Mobile*/
China Unicom*
Regulatory:
Global: GCF
Europe: CE
North America: PTCRB
America: FCC
Canada: IC
Brazil: Anatel
Mexico: IFETEL*
China:
SRRC*/NAL*/CCC*
South Korea: KC*
Taiwan China: NCC*
Japan: JATE*/TELEC*
Australia/New Zealand:
RCM
Thailand: NBTC*
Singapore: IMDA*
Others:
RoHS/ATEX*
Carrier:
Europe:
Vodafone*/
Deutsche Telekom*/
Telefónica*
America:
Verizon/ AT&T/
Sprint/T-Mobile*
Canada:
Rogers*/Telus*
China:
China Telecom*/
China Mobile*/
China Unicom*
Regulatory:
Global: GCF
Europe: CE
North America: PTCRB
America: FCC
Canada: IC
Brazil: Anatel
Mexico: IFETEL*
China:
SRRC*/NAL*/CCC*
South Korea: KC*
Taiwan China: NCC*
Japan: JATE*/TELEC*
Australia/New Zealand: RCM
Thailand: NBTC*
Singapore: IMDA*
Others:
RoHS/PEN/ATEX*
Carrier:
TBD
Regulatory:
TBD
Others:
TBD
LPWA Module
BG95-M4
BG95-M5
BG95-M6
BG95-MF*
Region/Operator
For the Global
For the Global
For the Global
For the Global
LTE FDD
Cat M1:
B1/B2/B3/B4/B5/B8/
B12/B13/B18/B19/
B20/B25/B26/B27/B28/
B31①/B66/B72①/
B73①/B85
Cat NB2:
B1/B2/B3/B4/B5/B8/
B12/B13/B18/B19/B20/
B25/B28/B31①/B66/
B72①/B73①/B85
Cat M1:
B1/B2/B3/B4/B5/B8/
B12/B13/B18/B19/
B20/B25/B26/B27/B28/
B66/B85
Cat NB2:
B1/B2/B3/B4/B5/B8/
B12/B13/B18/B19/B20/
B25/B28/B66/B71/B85
Cat M1:
B1/B2/B3/B4/B5/B8/
B12/B13/B18/B19/
B20/B25/B26/B27/
B28/B66/B85
Cat NB2:
B1/B2/B3/B4/B5/B8
/B12/B13/B18/B19/
B20/B25/B28/B66/
B71/B85
Cat M1:
B1/B2/B3/B4/B5/B8/
B12/B13/B18/B19/
B20/B25/B26/B27/B28/
B66/B85
Cat NB2:
B1/B2/B3/B4/B5/B8/
B12/B13/B18/B19/B20/
B25/B28/B66/B71/B85
GSM/EDGE
/
850/900/1800/1900 MHz
/
/
GNSS (Optional)
GPS/GLONASS/BeiDou/
Galileo/QZSS
GPS/GLONASS/BeiDou/
Galileo/QZSS
GPS/GLONASS/BeiDou/
Galileo/QZSS
GPS/GLONASS/BeiDou/
Galileo/QZSS
Wi-Fi (For Positioning)
/
/
/
2.4 GHz
Certification
Carrier:
/
Regulatory:
Europe: CE*
Brazil: Anatel*
Others:
RoHS*
Carrier:
Europe: Vodafone*/
Deutsche Telekom*
America:
Verizon*/AT&T*/T-Mobile*/Sprint*
China:
China Telecom*/
China Mobile*/
China Unicom*
South Korea:
SKT*/LGU+*
Japan:
NTT DOCOMO*/
SoftBank*/KDDI*
Australia: Telstra*
Regulatory:
Global: GCF*
Europe: CE*
North America:
PTCRB*
America: FCC*
Canada: IC*
China:
SRRC*/NAL*/CCC*
South Korea: KC*
Taiwan China: NCC*
Japan: JATE*/TELEC*
Australia/New Zealand: RCM*
Thailand: NBTC*
Singapore: IMDA*
Others:
RoHS
Carrier:
Europe:
Vodafone*/
Deutsche Telekom*
America:
Verizon*/AT&T*/
T-Mobile*/Sprint*
China:
China Telecom*/
China Mobile*/
China Unicom*
South Korea:
SKT*/LGU+*
Japan:
NTT DOCOMO*/
SoftBank*/KDDI*
Australia: Telstra*
Regulatory:
Global: GCF*
Europe: CE*
North America:
PTCRB*
America: FCC*
Canada: IC*
China:
SRRC*/NAL*/CCC*
South Korea: KC*
Taiwan China: NCC*
Japan: JATE*/TELEC*
Australia/New Zealand:
RCM*
Thailand: NBTC*
Singapore: IMDA*
Others:
RoHS
Carrier:
/
Regulatory:
Global: GCF*
Europe: CE*
North America:
PTCRB*
America: FCC*
Canada: IC*
Australia/New Zealand:
RCM*
Others:
RoHS
* means under development/on-going/planning.
① means LTE-FDD B31/B72/B73 for BG95-M4 supports Power Class 2* and Power Class 3.
