Original New LPWA Module BG95-M3 Cat M1/ Cat NB2/ EGPRS Module, BG95 Series BG95-M1 BG95-M2 BG95-M6
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1999
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LTE BG95 Cat M1/ Cat NB2/ EGPRS Module, LPWA Module BG95-M1 BG95-M2 BG95-M3 BG95-M4 BG95-M5NegotiableMOQ: 1 -
Original New LTE BG96 Cat M1/NB1/EGPRS Module, NB-IoT Module BG96NegotiableMOQ: 1
-
BG96 LTE Cat M1/Cat NB1/EGPRS Module, LPWA NB-IoT Module BG96NegotiableMOQ: 1
-
SIMCOM SIM868 GPS GSM Module SIM868 2G GPS ModuleNegotiableMOQ: 1
-
LTE Advanced Category 6 Module EG06 EG06-A EG06-ENegotiableMOQ: 1
Description
LTE BG95 Cat M1/ Cat NB2/ EGPRS Module
Overview
BG95 is a series of multi-mode LPWA modules supporting LTE Cat M1/Cat NB2/EGPRS and integrated GNSS. It is 3GPP Rel-14 compliant and offers maximum data rates of 588 kbps downlink and 1119 kbps uplink under LTE Cat M1. It features ultra-low power consumption by leveraging the integrated RAM/flash as well as the ARM Cortex A7 processor supporting ThreadX, achieving up to 70% reduction in PSM leakage and 85% reduction in eDRX current consumption compared to its predecessor.
BG95 boasts a comprehensive set of hardware-based security features and enables trusted applications to run directly on the Cortex A7 TrustZone engine. Additionally, BG95 provides pin-to-pin compatibility with LTE Cat 4 modules EG91/EG95, LTE Cat M1/Cat NB1/EGPRS module BG96, NB-IoT module BC95, UMTS/HSPA modules UG95/UG96 and GSM/GPRS module M95.
With a cost-effective SMT form factor of 23.6 mm × 19.9 mm × 2.2 mm and high integration level, BG95 enables integrators and developers to easily design their applications and take advantage from the module's low power consumption and mechanical intensity. Its advanced LGA package allows fully automated manufacturing for high-volume applications. A rich set of Internet protocols, industry-standard interfaces and abundant functions extend the applicability of the module to a wide range of M2M applications such as wireless POS, smart metering, tracking, wearable devices, etc.
Key Features
● LTE Cat M1/Cat NB2/EGPRS module with ultra-low power consumption
● Easy migration from GSM/GPRS, UMTS/HSPA and LTE modules
● Integrated RAM and flash in the baseband chipset
● Comprehensive set of hardware-based security features
●Support VoLTE* (Cat M1 only), CS voice* for GSM, QuecOpen®, eSIM, etc.
● Fast time-to-market: reference designs, evaluation tools and timely technical support minimize design-in time and development efforts
● Compact SMT form factor ideal for size-constrained applications with tight space
● Robust mounting and interfaces
LPWA Module | BG95-M1 | BG95-M2 | BG95-M3 | BG95-N1 | ||
Region/Operator | For the Global | For the Global | For the Global | For the Global | ||
LTE FDD | Cat M1 Only: B1/B2/B3/B4/B5/B8/ 12/B13/B18/B19/ B20/B25/B26/B27/B28/ B66/B85 | Cat M1: B1/B2/B3/B4/B5/B8/ B12/B13/B18/B19/ B20/B25/B26/B27/B28/ B66/B85 Cat NB2: B1/B2/B3/B4/B5/B8/ B12/B13/B18/B19/B20/ B25/B28/B66/B71/B85 | Cat M1: B1/B2/B3/B4/B5/B8/ B12/B13/B18/B19/ B20/B25/B26/B27/B28/ B66/B85 Cat NB2: B1/B2/B3/B4/B5/B8/ B12/B13/B18/B19/B20/ B25/B28/B66/B71/B85 | Cat NB2 Only: B1/B2/B3/B4/B5/B8/ B12/B13/B18/B19/B20/ B25/B28/B66/B71/B85 | ||
GSM/EDGE | / | / | 850/900/1800/1900 MHz | / | ||
GNSS (Optional) | GPS/GLONASS/BeiDou/ Galileo/QZSS | GPS/GLONASS/BeiDou/ Galileo/QZSS | GPS/GLONASS/BeiDou/ Galileo/QZSS | GPS/GLONASS/BeiDou/ Galileo/QZSS | ||
Wi-Fi (For Positioning) | / | / | / | / | ||
Certification | Carrier: America: Verizon/AT&T/ Sprint Regulatory: Global: GCF Europe: CE North America: PTCRB America: FCC Canada: IC Japan: JATE*/TELEC* Australia/New Zealand: RCM Others: RoHS | Carrier: Europe: Vodafone*/ Deutsche Telekom*/ Telefónica* America: Verizon/AT&T/Sprint/ T-Mobile* Canada: Rogers*/Telus* China: China Telecom*/ China Mobile*/ China Unicom* Regulatory: Global: GCF Europe: CE North America: PTCRB America: FCC Canada: IC Brazil: Anatel Mexico: IFETEL* China: SRRC*/NAL*/CCC* South Korea: KC* Taiwan China: NCC* Japan: JATE*/TELEC* Australia/New Zealand: RCM Thailand: NBTC* Singapore: IMDA* Others: RoHS/ATEX* | Carrier: Europe: Vodafone*/ Deutsche Telekom*/ Telefónica* America: Verizon/ AT&T/ Sprint/T-Mobile* Canada: Rogers*/Telus* China: China Telecom*/ China Mobile*/ China Unicom* Regulatory: Global: GCF Europe: CE North America: PTCRB America: FCC Canada: IC Brazil: Anatel Mexico: IFETEL* China: SRRC*/NAL*/CCC* South Korea: KC* Taiwan China: NCC* Japan: JATE*/TELEC* Australia/New Zealand: RCM Thailand: NBTC* Singapore: IMDA* Others: RoHS/PEN/ATEX* | Carrier: TBD Regulatory: TBD Others: TBD | ||
LPWA Module | BG95-M4 | BG95-M5 | BG95-M6 | BG95-MF* | ||
Region/Operator | For the Global | For the Global | For the Global | For the Global | ||
LTE FDD | Cat M1: B1/B2/B3/B4/B5/B8/ B12/B13/B18/B19/ B20/B25/B26/B27/B28/ B31①/B66/B72①/ B73①/B85 Cat NB2: B1/B2/B3/B4/B5/B8/ B12/B13/B18/B19/B20/ B25/B28/B31①/B66/ B72①/B73①/B85 | Cat M1: B1/B2/B3/B4/B5/B8/ B12/B13/B18/B19/ B20/B25/B26/B27/B28/ B66/B85 Cat NB2: B1/B2/B3/B4/B5/B8/ B12/B13/B18/B19/B20/ B25/B28/B66/B71/B85 | Cat M1: B1/B2/B3/B4/B5/B8/ B12/B13/B18/B19/ B20/B25/B26/B27/ B28/B66/B85 Cat NB2: B1/B2/B3/B4/B5/B8 /B12/B13/B18/B19/ B20/B25/B28/B66/ B71/B85 | Cat M1: B1/B2/B3/B4/B5/B8/ B12/B13/B18/B19/ B20/B25/B26/B27/B28/ B66/B85 Cat NB2: B1/B2/B3/B4/B5/B8/ B12/B13/B18/B19/B20/ B25/B28/B66/B71/B85 | ||
GSM/EDGE | / | 850/900/1800/1900 MHz | / | / | ||
GNSS (Optional) | GPS/GLONASS/BeiDou/ Galileo/QZSS | GPS/GLONASS/BeiDou/ Galileo/QZSS | GPS/GLONASS/BeiDou/ Galileo/QZSS | GPS/GLONASS/BeiDou/ Galileo/QZSS | ||
Wi-Fi (For Positioning) | / | / | / | 2.4 GHz | ||
Certification | Carrier: / Regulatory: Europe: CE* Brazil: Anatel* Others: RoHS* | Carrier: Europe: Vodafone*/ Deutsche Telekom* America: Verizon*/AT&T*/T-Mobile*/Sprint* China: China Telecom*/ China Mobile*/ China Unicom* South Korea: SKT*/LGU+* Japan: NTT DOCOMO*/ SoftBank*/KDDI* Australia: Telstra* Regulatory: Global: GCF* Europe: CE* North America: PTCRB* America: FCC* Canada: IC* China: SRRC*/NAL*/CCC* South Korea: KC* Taiwan China: NCC* Japan: JATE*/TELEC* Australia/New Zealand: RCM* Thailand: NBTC* Singapore: IMDA* Others: RoHS | Carrier: Europe: Vodafone*/ Deutsche Telekom* America: Verizon*/AT&T*/ T-Mobile*/Sprint* China: China Telecom*/ China Mobile*/ China Unicom* South Korea: SKT*/LGU+* Japan: NTT DOCOMO*/ SoftBank*/KDDI* Australia: Telstra* Regulatory: Global: GCF* Europe: CE* North America: PTCRB* America: FCC* Canada: IC* China: SRRC*/NAL*/CCC* South Korea: KC* Taiwan China: NCC* Japan: JATE*/TELEC* Australia/New Zealand: RCM* Thailand: NBTC* Singapore: IMDA* Others: RoHS | Carrier: / Regulatory: Global: GCF* Europe: CE* North America: PTCRB* America: FCC* Canada: IC* Australia/New Zealand: RCM* Others: RoHS | ||
* means under development/on-going/planning.
① means LTE-FDD B31/B72/B73 for BG95-M4 supports Power Class 2* and Power Class 3.
① means LTE-FDD B31/B72/B73 for BG95-M4 supports Power Class 2* and Power Class 3.
