SIMCOM SIM7000A SIM7000E SIM7000G 4G Module LTE IoT NB-IoT LPWA Module

Name: SIMCOM SIM7000A SIM7000E SIM7000G 4G Module LTE IoT NB-IoT LPWA Module
Price: Negotiable

FOB Price

Negotiable

1 (Min.Order)

Supply Ability 1000 per Month
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Description

Description

SIM7000X Cat-M/NB-IoT/GSM

The SIM7000 series has powerful expansibility with abundant interfaces including UART, GPIO, PCM, I2C etc. The SIM7000 series is designed for applications that need low latency, low throughput data communication in a variety of radio propagation conditions. Due to the unique combination of performance, security and flexibility, this module is ideally suited for M2M applications, such as metering, asset tracking, remote monitoring, E-health etc.

Product Advantages ● With Power Saving Mode(PSM) and Extended Discontinuous Reception(eDRX), the SIM7000 series can extend battery life to 10 years ● SIM7000 series provides deeper coverage enhancement compared to GSM ● The form factor and AT commands of the SIM7000 series are compatible with SIM900 and SIM800F

Product	SIM7000G	SIM7000E	SIM7000A	SIM7000JC	SIM7000C
Form factor	LCC, 68PIN	LCC, 68PIN	LCC, 68PIN	LCC, 68PIN	LCC, 68PIN
Dimensions(mm)	24242.6	24242.6	24242.6	24242.6	24242.6
Frequency Bands
Cat-M	B1/B2/B3/B4/B5/B8/B12/B13/B17/ B18/B19/B20/B25/B26/B28/B39	B3/B5/B8/B20/B28	B2/B4/B12/B13	B1/B3/B5/B8/B18/B19/B26	B1/B3/B5/B8
Cat-NB	B1/B2/B3/B4/B5/B8/B12/B13/B17/ B18/B19/B20/B25/B26/B28	B3/B5/B8/B20/B28	B2/B4/B12/B13	B1/B3/B5/B8/B18/B19/B26	B1/B3/B5/B8
GSM	850/900/1800/1900MHz	900/1800MHz			900/1800MHz
GNSS	o	o	o	o	o
Temperature	-40℃ ~ +85℃	-40℃ ~ +85℃	-40℃ ~ +85℃	-40℃ ~ +85℃	-40℃ ~ +85℃
Electrical Features
Supply Voltage Range(V)	3.0~ 4.3	3.0~ 4.3	3.0~ 4.3	3.0~ 4.3	3.0~ 4.3
Power Consumption
Power Off(uA)	7	7	7	7	7
PSM(uA)	9	9	9	9	9
Sleep(mA)	1	1	1	1	1
Idle(mA)	11	11	11	11	11
Data Transfer
Cat-M(Kbps)	300(DL)/375(UL)	300(DL)/375(UL)	300(DL)/375(UL)	300(DL)/375(UL)	300(DL)/375(UL)
Cat-NB(Kbps)	34(DL)/66(UL)	34(DL)/66(UL)	34(DL)/66(UL)	34(DL)/66(UL)	34(DL)/66(UL)
EGPRS(Kbps)	85.6(DL)/85.6(UL)	85.6(DL)/85.6(UL)			85.6(DL)/85.6(UL)
Software Features
Protocol	TCP/UDP/LWM2M/COAP/MQTT/ FTP/HTTP/TLS/DTLS/NTP	TCP/UDP/LWM2M/COAP/MQTT/ FTP/HTTP/TLS/DTLS/NTP	TCP/UDP/LWM2M/COAP/MQTT/FTP/HTTP/TLS/DTLS/NTP	TCP/UDP/LWM2M/COAP/MQTT/ FTP/HTTP/TLS/DTLS/NTP	TCP/UDP/LWM2M/COAP/MQTT/FTP/HTTP/TLS/DTLS/NTP
FOTA	●	●	●	●	●
Embedded AT	●	●	●	●	●
Firmware Upgrade	USB/FOTA	USB/FOTA	USB/FOTA	USB/FOTA	USB/FOTA
Interfaces
SIM Card	1.8V/3.0V	1.8V/3.0V	1.8V/3.0V	1.8V/3.0V	1.8V/3.0V
UART	●	●	●	●	●
USB	●	●	●	●	●
PCM	●	●	●	●	●
ADC	●	●	●	●	●

I2C	●	●	●	●	●
Certification
Regulatory	FCC/IC/CE/3C/GCF/RoHS/REACH	CE/RCM/IMDA/GCF/RoHS/REACH	FCC/IC/GCF/RoHS/REACH	JATE/TELEC/RoHS/REACH	CCC/NAL/SRRC/RoHS/REACH
Carrier	Deutsche Telekom /ORANGE*/ PTCRB	TELSTRA/VDF/ORANGE/TIM*/ GCF/Deutsche Telekom	AT&T/VERIZON/ ROGERS*/PTCRB/GCF	KDDI/DoCoMo*	CMCC/CUCC/CT
●: support o: optional * : on going

Why Choose Us

FAQ

Q1. What is the minimum order quantity for your products? A1. Minimum order quantity starts from ONE piece. Q2. What's the quality of your products? A2. We have professional QA/QC team to ensure the quality before shipment. We provide 1 year warranty for all the new and original products. Q3. Is this product free of shipping or free samples? A3. Regularly the sample and shipping cost will be at the buyer's account. But in specific case, we may take these costs. Please kindly check with us the details by email. Thank you.
