Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > SIMCOM SIM8200EA-M2 Multi-Band 5G NR/LTE-FDD/LTE-TDD/HSPA+ Module Up to 4Gbps Data Transfer, 5G Module SIM8200EA SIM8200 M2
SIMCOM SIM8200EA-M2 Multi-Band 5G NR/LTE-FDD/LTE-TDD/HSPA+ Module Up to 4Gbps Data Transfer, 5G Module SIM8200EA SIM8200 M2
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Association
Year Established:
1999
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SIMCOM SIM8200EA-M2 Multi-Band 5G NR/LTE-FDD/LTE-TDD/HSPA+ Module, 5G Module up to 4Gbps Data Transfer SIM8200EA SIM8200NegotiableMOQ: 1 -
SIM7906E-PCIE LTE Cat 6 Module, 4G LTE-A Module SIMCOM SIM7906E PCIeNegotiableMOQ: 1
-
SIMCOM SIM7906-M2 LTE Cat 6 Module 300Mbps Downlink and 50Mbps Uplink Rate, LTE-A Module SIM7906E-M2 SIM7906SA-M2NegotiableMOQ: 1
-
SIM7906-M2 LTE Cat6 Module 300Mbps Downlink Rate, LTE-A Module SIM7906E SIM7906SA M2 Form FactorNegotiableMOQ: 1
-
SIMCOM SIM7912G SIM7912 M2 Type LTE Cat12 Module, 4G LTE Module LTE SIM7912G-M2NegotiableMOQ: 1
Description
SIM8200EA-M2
● The SIM8200EA-M2 is the Multi-Band 5G NR/LTE-FDD/LTE-TDD/HSPA+ module which supports R15 5G NSA/SA up to 4Gbps data transfer.
● It has strong extension capability with rich interfaces including UART,PCIe,USB3.1, GPIO etc. The module provides much flexibility and ease of integration for customer's application.
● The SIM8200EA-M2 adopts M.2 form factor, TYPE 3052-S3-B. AT commands of SIM8200-M2 series are compatible with SIM7912G/SIM8300G-M2 series modules. This also minimizes the investments of customers, and enables a short time-to-market.
● It is designed for applications that need high throughput data communication in a variety of radio propagation conditions. Due to the unique combination of performance, security and flexibility, this module is ideally suited for many applications.
Product Advantages
● Standard M.2 interface.
● High throughput data communication.
● AT commands of the SIM8200EA-M2 is compatible with SIM7912G/SIM8300G-M2 series modules
Product |
SIM8200EA-M2 |
||||
Form Factor |
M.2 |
||||
Dimensions(mm) |
52.0*30.0*2.3 |
||||
Frequency Bands |
Sub-6G |
||||
LTE-FDD |
B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/ B20/B25/B26/B28/B29/B30/B66/B71 |
||||
LTE-TDD |
B34/B38/B39/B40/B41/B42/B48 |
||||
WCDMA |
B1/B2/B3/B4/B5/B8 |
||||
Temperature |
-30℃ ~ +70℃ |
||||
Electrical Features |
|||||
Supply Voltage(V) |
3.135 ~ 4.4 |
||||
Data Transfer |
|||||
Sub-6G |
4Gbps(DL)/500Mbps(UL) |
||||
LTE |
2Gbps(DL)/200Mbps(UL) |
||||
HSPA+ |
42Mbps (DL)/5.76Mbps(UL) |
||||
Software Features |
|||||
Protocol |
TCP/IP/IPV4/IPV6/Multi-PDP/FTP/FTPS/HTTP/HTTPS/MQTTS/DNS/SSL3.0 |
||||
TLS |
● |
||||
File System |
● |
||||
FOTA |
● |
||||
Android RIL |
Android 6/7/8/9 |
||||
USB Driver |
Microsoft Windows Win7/Win8/Win10/Linux/Android |
||||
MBIM |
Win8/Win10 |
||||
NDIS |
Linux/Win7/Win8/Win10 |
||||
Firmware Upgrade |
USB |
||||
Interfaces |
|||||
SIM Card |
1.8V/2.95V |
||||
UART |
● |
||||
USB |
● |
||||
PCM |
● |
||||
I2C |
● |
||||
Diversity Receiver |
● |
||||
Certifications |
|||||
Regulatory |
RoHSREACHCCCCTASRRCMobileUnicomTelecomRCMCE(RED)GCF |
||||
