Quick Details
Place of Origin: Zhejiang, China (Mainland)
Brand Name: UNIRISING
Model Number: sp-021 LMR400 coaxial cable
Conductor Material: CU/CCS/CCA/TC
Insulation Material: PE/FPE/SPE
Jacket: PE/PVC
Number of Conductors: one
Application: TV
color: black
type: LMR400 coaxial cable
Packaging & Delivery
| Packaging Details: | Lengths: 100, 200 or 305m/roll and 100, 200 or 300 yards/roll Various lengths are available (customized) Inner: wooden, plastic and paper reel for LMR400 coaxial cable.Outer: carton box, pull-out box and pallet Other packing available according to customer requests |
|---|---|
| Delivery Detail: | 7-15days for LMR400 coaxial cable |
Specifications
superlink LMR400 coaxial cable
1. OEM producing
2. short time delivery
3. Good quality
petitive price
competitive price LMR400 coaxial cable
*Operating characteristics
·Environment temperature: -25°C~70°C
·The cables have even characteristic impedance.
·Low loss, low propagation delay and minimum attenuation.
·Packing : Coil packing, 100M,200M/roll or 305M/roll
*products specifications
| Inner Conductor | Material | CCS/CCA/CU |
| Diam(ø)mm | 2.74mm | |
| Insulation | Material | PE/FPE/SPE |
| Diam(ø)mm | 7.24mm | |
| First shield | Material | AL FOIL |
| Diam(ø)mm | AL FOIL | |
| Second Shield | Material | AL/BC/TC |
| Diam(ø)mm | 0.12mm | |
| wire quantity | 168 | |
| Coverage | 90% | |
| Jacket | Material | PVC ( Flame Retardant /RoHS ) |
| Thickness(mm) | min 0.55 | |
| Diam(ø)mm | 10.29mm | |
| Color | Black |
FAQ:
Q1: What kind of cable do you produce?
A: We specialized in producing Fire alarm cables, Alarm/security cables, Speaker cables, Coaxial cables, Data cables, HDMI cables, telecommunication cables, telephone cables, power cables ,silicone rubber , teflon cable,wire harnessand other various of cables and wires
We also provide cable accessory products such as connector, cable clip,cable tie,crimping tool, antenna dishe,splitters,amplifer,optical receiver,optical transmitter etc
Q2: What's your MOQ? Can you offer free samples?
A: Our MOQ is 10KM per item. Free samples can be sent to you if available in stock,freight cost need to be paid by your side.
Q3: What's your delivery time?
A: Normally, our delivery time is 15 days after received deposit,it base on the quantity of the order.
Q4: What's your payment term?
A: We accept T/T, L/C,Western Union.Other payments accept through negotiation.
Q5:What's your trade term?
A: We accept FOB ShangHai or Ningbo,CFR,CIF,EXW term
