Help CenterModule Spare Parts CSA463AE HIEE400103R0001
Related Products
-
Module Spare Parts CSA464AE HIEE400106R0001US$ 1 - 100000MOQ: 1 Piece -
Module Spare Parts D136-001-001US$ 1 - 100000MOQ: 1 Piece
-
Module Spare Parts D136-001-007US$ 1 - 100000MOQ: 1 Piece
-
Module Spare Parts D138-002-002US$ 1 - 100000MOQ: 1 Piece
-
Module Spare Parts D20 EME 10BASE-TUS$ 1 - 100000MOQ: 1 Piece
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
| CSA463AE HIEE400103R0001 |
Fiber optic connections The BCU-02 control unit has two fiber optic connections V1 and V2 for connecting to converter modules. The BCU-12 control unit has one BPEB-05 board, and the BCU-22 control unit has two BPEB-05 boards. Each BPEB-05 board adds five fiber optic connections. Thus, the BCU-12 has seven connections (V1…V7), and the BCU-22 has twelve connections (V1…V12). The maximum lengths of the cables are: • 1 mm plastic optical fiber cables, 35 m (115 ft) • 200 μm hard-clad silica fiber cables, 100 m (328 ft). Fiber optic pairs connected to one control unit must have the same length. With long distances, cables of different length cause different delays, which can have an unwanted effect on the operation. For instructions on how to connect the control unit to the converter module(s), see the applicable converter hardware manual. V1 V2 V3 V4 V5 V6 V7 V8 V9 V10 V11 V12 xINT Module 1 xINT Module 3 I/O BPEB-05 BCU-x2 BIOC-01 BPEB-05 xINT Module 2 xINT Module 7 xINT Module 8 xINT Module 12 Hardware description 11 Layout The figures show the layout of the BCU-22 control unit. For the default I/O connection diagrams and more information on the connections, see the applicable converter hardware manual. 12 Hardware description The label describes the location of the I/O connectors and has the same colors as the connectors. Label Hardware description 13 Description I/O connector XAI Analog input XAO Analog output XDI Digital input and digital start interlock XDIO Digital input/output XD2D Drive-to-drive link XD24 +24 V output for digital input XPOW External power input XRO1 Relay output 1 XRO2 Relay output 2 XRO3 Relay output 3 XSTO Safe torque off connection (input signal). Note: This input only acts as a true Safe torque off input in control units controlling a motor. In other applications (such as a supply or brake unit), de-energizing the IN1 and/or IN2 terminal will stop the unit but does not constitute a true safety function. For more information on Safe torque off, see the applicable converter hardware manual. XSTO OUT Safe torque off connection (output for powering XSTO input of inverter modules). X485 Not in use Switch AI1 Analog input 1 current/voltage selection AI2 Analog input 2 current/voltage selection D2D TERM Drive-to-drive link termination DICOM = DIOGND Determines whether DICOM is separated from DIOGND (ie, common reference for digital inputs floats). Fiber optic connector V1T…V12T, V1R…V12R Fiber optic connector to converter module: T = Transmitter, R = Receiver Connector for optional module SLOT 1 F-type adapter, interface and I/O extension modules If FDPI-02 diagnostics and panel interface is used, it has to be installed in slot 1 with two screws.
