Module Spare Parts D136-001-007
Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
| D136-001-007 |
Installing the control unit The control unit is grounded through the DIN rail. Vertical DIN rail mounting 1. Attach the latches to the back of the control unit with four screws for each latch. 2. Push the control unit to the rail as shown below. It makes a click. 3. To prevent movement of the control unit, attach it to the rail with screws (a), or end brackets (b), or both. 1 2 2 3a 1 3b 18 Installation Horizontal DIN rail mounting 1. Attach the latches to the back of the control unit with four screws for each latch. 2. Push the control unit to the rail as shown below. It makes a click. 3. (Optional) To prevent movement of the control unit, attach it to the rail with screws or end brackets. 1 1 3 2 2 Installation 19 Installing the FSO-xx safety functions module 1. Install the FSO-xx safety functions module onto slot 3 with four screws. 2. Tighten the FSO-xx electronics grounding screw. Tightening torque 0.8 N·m (7.1 lbf·in). 3. Connect the FSO-xx data cable to FSO-xx connector X110 and to BCU connector X12. 1 3 2 20 Installation Electrical installation WARNING! Obey the safety instructions given in ACS880 multidrive cabinets and modules safety instructions (3AUA0000102301 [English]), or ACS880 liquidcooled multidrive cabinets and modules safety instructions (3AXD50000048633 [English]), or ACS880-04XT drive modules (500 to 1200 kW) hardware manual (3AXD50000025169 [English]). If you ignore the safety instructions, injury or death can occur. If you are not a qualified electrician, do not do electrical work. Connect the +24 V external power supply to the control unit connector XPOW. You can connect a second power supply for redundancy. Connect the fiber optic cables from the converter module to the control unit. Refer to the instructions given in the converter module hardware manual. Related documents For general electrical installation instructions, see ACS880 multidrive cabinets and modules electrical planning instructions (3AUA0000102324 [English]), or ACS880 liquidcooled multidrive cabinets and modules electrical planning (3AXD50000048634 [English]) and the applicable converter hardware manual, or ACS880-04XT drive modules (500 to 1200 kW) hardware manual (3AXD50000025169 [English]). For information on the electrical installation of the FSO-xx safety functions module, see the applicable FSO-xx safety functions module user's manual. For the default I/O connection diagrams and more information on the connections, see the applicable converter hardware manual.
