Product Description
High temperature high pressure Float flow meter gas flow meter air flow meter
Flowmeter ,Float Flowmeter, Metal Tube Float Flowmeter, Rotameter, Metal Tube Rotameter
Flow meter, Float Flow meter, Metal Tube Folat Flow meter, gas flow meter, air flow meter
used in the industrial automation process management to measure the variable areaflow.
small size, wide application range, convenient usage.
applicable for measuring the flows of liquids, gases and steam, especially measurement of low flow speed and small flow rate.
1.1 Functional Features of Metal Tube float flow meter
Float flow meter gas flow meter air flow meter
- Designed for measurement of small caliber and low-speed medium
- With reliable performance, few maintenance and long service life
- Low requirement for the straight tube section
- Widely measure ratio: 10:1
- Dual-line display, instantaneous/ cumulative flow rates displayed at the field
- With a keyboard on the indictor for convenient operation and setting
- All in metal construction, designed for measuring corrosive medium of high temperature, high pressure and strong
- Non-contact magnetic coupling transmission
- Applicable for inflammable and explosive occasion
- Optional charging modes: DC power supply or battery power
- With the functions of data recovery, data backup and power failure protection
- Multiple parameters calibrating function.
1.2 Specification of Metal Tube float flow meter
Float flow meter gas flow meter air flow meter
|
Caliber of flow meter |
DN15, DN25, DN50, DN80, DN100, DN150 |
|
Range of flow |
Liquid: 1.0~150000l/h |
|
Gas: 0.05~3000m3/h |
|
|
Measure Ratio |
10:1 |
|
20:1 (special) |
|
|
Caliber Precision |
Grade 0.5 |
|
Grade 1.0 (special) |
|
|
Pressure rating |
DN15, DN25, DN50: 4.0Mpa (Max: 20Mpa) |
|
DN80, DN100, DN150:1.6MPa |
|
|
(DN80:Max 10Mpa; DN100:Max 6.4Mpa; DN150:Max 4.0Mpa) |
|
|
Connection method |
Flange,Flange standard: GB/T9119-2000 |
|
Cable interface |
M20*1.5 |
|
Protection grade |
IP65 |
|
Power supply |
24VDC (12~36VDC) |
|
Medium temperature |
Standard:-30°C to +120°C |
|
high temperature: 120°C to 350°C |
|
|
Environment temperature |
Local type: -40°C to 120°C |
|
Remote-control type: -30°C to 60°C |
|
|
Output signal |
4~20mADC (two-wire configuration) |
|
attached HART Protocol allowed |
|
|
Output load |
500 ohm (24V power supply) |
|
Storage requirement |
Temperature: -40°C to 85°C |
|
Humidity:≤85% |
|
|
Mark of explosion-proof |
Intrinsic safety type: ExiaIICT6 |
|
explosion-proof type: ExdIICT6 |
|
|
Pressure loss |
See table of flow for detailed information |
|
Viscosity of medium |
DN15:η<5mPa.s |
|
DN25:η<250mPa.s |
|
|
DN50~DN150:η<300mPa.s |
|
|
Contact material |
R1: 304, 1Cr18Ni9Ti |
|
Ro: 316, 0Cr18Ni12Mo2Ti |
|
|
RL: 316L, 00Cr17Ni14Mo2Ti |
|
|
Ti: Titanium alloy |
|
|
Rp: PTFE lining |
1.3 Dimension and Type of Metal Tube float flow meter
Float flow meter gas flow meter air flow meter
1.4 Install of Metal Tube float flow meter
Float flow meter gas flow meter air flow meter
1.5 Coding Description of Metal Tube float flow meter
Float flow meter gas flow meter air flow meter
|
1 Construction type of sensor |
2 Material of contact area |
|
A Vertical installation type |
R1 304,1Cr18Ni9Ti |
|
3 Selection of indictors: |
|
|
M1 Mechanical pointer indicates the instantaneous flow rate; |
|
|
4 Explosion-proof type |
5 Measuring medium: |
|
i Intrinsic safety type(ExiaIICT6) |
L Liquid measurement |
|
6 Additional functions of the sensor: |
|
|
T Heat preservation/ cooling jacket |
|
|
7 Additional functions of the indictor: |
|
|
K1 Lower limit alarm |
|
|
8 Nominal diameter |
|
|
50 DN50 (Caliber of process pipelines) |
|
