Lab Scale Textile Fabric Electric Magnetic Printing Dyeing Machine
Negotiable
1 (Min. Order)
- T/T Credit Card
You May Like
Product Description
Product Description
AT288 Electric Laboratory Printing Machine (original model is HY0190) is magnetic printing machine that used for lab printing research.
Features
★ Floor type, no need desk and equipped with tool box.
★ Imported rubber for the coating table, high elasticity, more evenness printing
★ Different squeeze rollers selectable for different sample
★ Magnetic table is drive by high quality motor and ball screw
★ Stepless regulator to control the magnetic force, AC variable frequency speed control system control running speed
★ Stepless regulator to control the magnetic force, AC variable frequency speed control system control running speed
Specifications
Model | AT288 |
Printing area | 500*400mm |
Screen frame size | 640*480mm |
Magnetic roller diameter | Φ10 and 20mm (standard) Φ15, 25 mm (optional) |
Magnetic roller length | 500mm |
Travel space | 200 ~ 500mm stepless adjustable |
Printing speed | 0.6 ~ 6m/min adjustable |
Power supply | 220V, 50Hz |
Dimensions | 900mm×900mm×1020mm |
Weight | 120kg |
Weight | 6.4kg |
Packing & Delivery
Packaging Details | The normal package is wooden box (Size: L900mm*W900mm*H1020mm). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. |
Payment
Payment Item | T/T | EXW FOB CFR(C&F) CIF | 30% T/T in advance, paid the balance before shipment | ||
FOB | |||||
CFR(C&F) | 30% T/T in advance,paid the balance against copy of B/L | ||||
CIF | |||||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||||
West Union | Amount lower than 50,000usd | ||||
Delivery Time | 7~10 days after receiving payment for one container | ||||
