Aut
Applicable industry:
Fabric Inspection Folding Machine suitable for Knit,Woven,elastic fabric and other general fabric.
Technical parameter:
Detection width |
1900mm(or customize) |
Maximum roll diameter |
≤Φ600mm |
Rolling Speed |
0-60Y/min |
Power |
2100w |
Power Supply |
AC220V 50hz |
Fabric Input / Output type |
Roll to relax |
Weight |
700KG |
Dimension(L * W * H) |
2400*1800*1950mm |
Feature:
1.This machine is used for checking cloth color difference, drawnwork, stain, stray hair, damage and other defects. It can be used for checking cloth rewinding, checking pine cloth, dispersing and rewinding.
2.Speed regulation by frequency variation: Three frequency converters can protect the motor from overload, overvoltage and phase failure.
3.Automatic edging: infrared electronic eye monitoring, automatic correction, make the cloth neat and beautiful.
4.Accurate length measurement: equipped with electronic counter, yardmeter conversion, can be fixed length stop.
5. Spreading function: Forward and backward double dial cloth function, smooth the folds, dial the hemming.
6. Reverse and reverse function, can be re-checked cloth
