Home > Industrial Equipment & Components > Valve > Ball Valve > High Pressure Stainless Steel Valves Chinese Factory Gauge Valves Swagelok Type Instrument Valves
High Pressure Stainless Steel Valves Chinese Factory Gauge Valves Swagelok Type Instrument Valves
US$ 30 - 80
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Hikelok
Place of Origin:
China
Model Number:
GV1
Payment & Shipping
Payment Methods:
Port of Shipment:
Chengdu
Delivery Detail:
15 days
Related Products
-
Ultrahigh Pressure 15000 Psi HiP Autoclave Butech Type 1/4'' 3/8'' OD Fnpt Needle ValveUS$ 50 - 70MOQ: 1 Piece -
Ultrahigh Pressure 15000 Psi HiP Autoclave Butech Type 1/4'' 3/8'' OD Fnpt Ball Valve Full Bore Ball ValveUS$ 50 - 100MOQ: 1 Piece
-
Ultrahigh Pressure 20000 Psi HiP Autoclave Butech Type 1/4'' 3/8'' OD MP Needle ValveUS$ 50 - 150MOQ: 1 Piece
-
Ultrahigh Pressure 30000 Psi HiP Autoclave Butech Type Staineless Steel 1/4'' 3/8'' OD HP Needle ValveUS$ 50 - 200MOQ: 1 Piece
-
Ultrahigh Pressure 20000 Psi Autoclave HiP Butech Type 1/4'' 3/8'' 9/16'' OD Threading Tool Coning Tool Reseating ToolUS$ 70 - 200MOQ: 1 Piece
Brand Name
Hikelok
Place of Origin
China
Model Number
GV1
Material
Stainless Steel
Application
General
Structure
Control
Standard or Nonstandard
Standard
Pressure
High Pressure
Power
Manual
Port Size
1/8'', 1/4'', 3/4'', 1/2'', 1''
Media
Gas
Temperature of Media
High Temperature
Gauge Valve- GV1, GV2
* Maximum working pressures:
GV1 up to 6000 psig (413 bar)
GV2 up to 10000 psig (689 bar)
* Working temperature:
PTFE packing: from -65℉ to 450℉ (-54℃ to 232℃)
Graphite packing: from -65℉ to 1200℉ (-54℃ to 649℃)
* Orifice size: 0.16" (4.0 mm)
* Non-rotating lower stem, ball tip design
* Safety back seating seals in fully open position
* Rolled spindle operating threads
* Lubricant for stem thread isolated from the media
* Low torque operating T bar handle
* Handle of different colors available for option
