FM-204-200K Electronics/building Hardware/auto Parts/textile Digital Push Pull Force Gauge

Model

FM-204-200K

FM-204-500K

FM-204-1000K

Force Range

±200 kgf

±500 kgf

±1000 kgf

±1960 N

±4900 N

±9800 N

±440 Lbf

±1100 Lbf

±2200 Lbf

Resolution

0.01 kgf ( <100 kgf )

0.1 kgf ( ≥100 kgf )

0.01 kgf ( <100 kgf )

0.1 kgf ( ≥100 kgf )

0.01 kgf ( <100 kgf )

0.1 kgf ( ≥100 kgf )

0.01 N ( <1000N )

1 N ( ≥1000 N )

0.01 N ( <1000N )

1 N ( ≥1000 N )

0.01 N ( <1000N )

1 N ( ≥1000 N )

0.1 Lbf

0.1 Lbf ( < 1000 Lbf )
1Lbf ( ≥ 1000 Lbf )

0.1 Lbf ( < 1000 Lbf )
1Lbf ( ≥ 1000 Lbf )

Accuracy

±0.5% FS ±1 Digit

±0.5% FS ±1 Digit

±0.5% FS ±1 Digit

Unit

kgf, N, Lbf

kgf, N, Lbf

kgf, N, Lbf

Measurement State

Peak Value, Real Time Measurement

Peak Value, Real Time Measurement

Peak Value, Real Time Measurement

Display

2 Reversed 4 Digit LCD

2 Reversed 4 Digit LCD

2 Reversed 4 Digit LCD

Power Off

10 Mins Auto Power Off, Manual Power Off

10 Mins Auto Power Off, Manual Power Off

10 Mins Auto Power Off, Manual Power Off

Backlight

Blue Backlight

Blue Backlight

Blue Backlight

Safe Load

150% FS ( Buzzer Alarm Over 110% FS )

150% FS ( Buzzer Alarm Over 110% FS )

150% FS ( Buzzer Alarm Over 110% FS )

Power Supply

2 x 1.5 AA ( UM-3 ) Battery or 6VDC Power

2 x 1.5 AA ( UM-3 ) Battery or 6VDC Power

2 x 1.5 AA ( UM-3 ) Battery or 6VDC Power

Operating

Temperature: 0 ~ 40°C

Temperature: 0 ~ 40°C

Temperature: 0 ~ 40°C

Conditions

Humidity: <80%

Humidity: <80%

Humidity: <80%

Surrounding

No Vibration Source or Corrosive Mwdium

No Vibration Source or Corrosive Mwdium

No Vibration Source or Corrosive Mwdium

Weight

1165 g

1165 g

1165 g

Case Size

175 x 80 x 36 mm

175 x 80 x 36 mm

175 x 80 x 36 mm

Senor Size

181 x 54 x 30 mm

181 x 54 x 30 mm

181 x 54 x 30 mm

Standard Accessories

Digital Force Gauge

Sensor ( M12 Screw Hole )

2 Suspension Links

Manual

Carrying Case

Optional Accessories

Power Adapter
