4/8/16port optical fiber amplifier edfa



1.Product description

RB-HA5400 series is a high-power multi-ports EDFA with gain spectrum band within 1540~1563nm. It is designed for the application of single channel or 1~8 continuous ribbon channels (ITU wavelength). This series of EDFA offers a flexible and low-cost solution for CATV large area coverage of metropolises and medium-sized cities.

EDFA product, for its high quality, high reliable and high cost performance, is the ideal choice of the system integration and system operation.

RB-HA5400A EDFA: 1RU chassis, total output power >1000mW, offers 16 optical outputs at most.

RB-HA5400B EDFA: 2RU chassis, total output power >5000mW, offers 64 optical outputs at most.

2. Product Feature

•      1540~1563nm operating bandwidth

•      500~5000mW (27~37mW) high output power

•      Low noise, high performance, high reliability

•      8~32 uplink optical port, used in OLT

•      8~32 1550nm output optical port, multiplex 1310/1490nm data stream.

•      Can be compatible with any FTTx PON Technology:EPON/GEPON, GPON, BPON, DPON

•      Perfect RS232, SNMP

•      Efficient space, flexible installation and easy operation

•      Excellent P/P ratio



3. Technique Index

Performance

Index

Supplement

Min.

Typ.

Max.

Optical feature

Operating wavelength range

(nm)

1540



1563

CATV

Input power

(dBm)

-10

≥+3

+10



Total output power1)

(dBm)

27



32

1U

28



37

2U

Number of output ports



4



16

1U, SC/APC, LC/APC

8



32

1U, LC/APC

8



32

2U, SC/APC, LC/APC

16



64

2U, LC/APC

Each port output power

(dBm)

10



22



Difference of output power

(dB)

-0.5



+0.5



Output power adjustable range

 (dBm)

-6



0

RB-HA5400/P

Noise figure (Pin=0dBm)

(dB)





6.3



Polarization dependence loss

(dB)





0.3



Polarization dependence gain

(dB)





0.4



Polarization mode dispersion

(ps)





0.3



Input/output isolation

(dB)

30







Pump power leakage

(dBm)





-30



Echo loss

(dB)

55





APC

General feature

Network management interface



RJ45

SNMP

Series interface



RS232



Power supply

(V)

90



265

220VAC

30



72

-48VDC



4.Rollball Order Information

Model number

Total output power

Number of output port

Each port output power

Connector

HA5826A-08

26dBm(400mW)

8

15.0

SC/APC, LC/APC

HA5827A-08

27dBm(500mW)

8

16.0

SC/APC, LC/APC

HA5828A-08

28dBm(630mW)

8

17.0

SC/APC, LC/APC

HA5829A-08

29dBm(800mW)

8

18.0

SC/APC, LC/APC

HA5830B-08

30dBm(1000mW)

8

19.0

SC/APC, LC/APC

HA5830B-16

16

15.5

HA5831B-08

31dBm(1260mW)

8

20.0

SC/APC, LC/APC

HA5831B-16

16

16.5

HA5831B-32

32

13.0

LC/APC

HA5832B-08

32dBm(1600mW)

8

21.0

SC/APC, LC/APC

HA5832B-16

16

17.5

HA5832B-32

32

14.0

LC/APC

HA5833B-08

33dBm(2000mW)

8

22.0

SC/APC, LC/APC

HA5833B-16

16

18.5

HA5833B-32

32

15.0

LC/APC

HA5834B-16

34dBm(2500mW)

16

19.5

SC/APC, LC/APC

HA5834B-32

32

16.0

LC/APC

HA5835B-16

35dBm(3200mW)

16

20.5

SC/APC, LC/APC

HA5835B-32

32

17.0

LC/APC

HA5836B-16

36dBm(4000mW)

16

21.5

SC/APC, LC/APC

HA5836B-32

32

18.0

LC/APC

HA5837B-16

37dBm(5000mW)

16

22.5

SC/APC, LC/APC

HA5837B-32

32

19.0

LC/APC

Remark: 1. All optical amplifiers in HA5800 series with specified output power and output ports can be in 2U casing.

2. Please contact us for detailed datasheet of optical amplifier if special output power and output ports configuration is required.
