Buy Digital 4 ch 720P TVI/CVI/AHD Fiber Optic Video Converter Transmission china supplier
Negotiable
1 (Min.Order)
- 1000 per Month
- T/T Credit Card
You May Like
Product Description
Product Description
Specification
Optical | Wavelength | 1310nm&1470nm-1610nm |
Fiber Type | Single mode, single fiber(default) | |
Distance | 0km~80km | |
Fiber interface | FC(default) ST / SC (optional) | |
HD Video | Video Interface Number | 4 |
Physical Interface | BNC | |
Video input and output impedance | 75Ω (unbalanced) | |
Input level | >500mVp-p | |
Output level | 1Vp-p | |
Bandwidth | 30MHz(720P); 60MHz(1080P) 150MHz(1960P) | |
Digit bit width | 8bit | |
Support camera pixels | 3 megapixel, 4 megapixel, 5 megapixel |
Video pixel | 1280（H）* 720（V） 1920（H）* 1080（V） 2560（H）* 1960（V） | |
Signal to noise ratio | > 60dB (weighted) (8Bit) | |
Data | Physical Interface | The industry standard connecting terminal |
Interface Signal | RS485 | |
Baud Rate | 1200~9600bit/s | |
BER | < 10 -9 | |
Electrical & Mechanical | Input Power Requirements | DC 5V |
Power Adapter | AC 100V~240V | |
Dimensions | 16.7*11.3*2.8cm | |
Packing | 34*25*5.5 cm | |
Weight | 1.3kg | |
Environmental | Operating temperature | -20°C ~ +75°C |
Storage temperature | -40°C ~ +85°C | |
Working humidity | 0% ~ 95% (non-condensing) | |
MTBF | >100,000 hours |
Packing & Delivery
Model No. | Product description |
PG-4V-TF-720 | 720P 4 x TVI/CVI/AHD video;FC 20km;Transmitter |
PG-4V-RF-720 | 720P 4 x TVI/CVI/AHD video;FC 20km;Receiver |
PG-4V1D-TF-720 | 720P 4 x TVI/CVI/AHD video+1 ch reverse RS485 data;FC 20km;Transmitter |
PG-4V1D-RF-720 | 720P 4 x TVI/CVI/AHD video+1 ch reverse RS485 data;FC 20km;Receiver |
PG-4V-TF-1080 | 1080P 4 x TVI/CVI/AHD video;FC 20km;Transmitter |
PG-4V-RF-1080 | 1080P 4 x TVI/CVI/AHD video;FC 20km;Receiver |
PG-4V1D-TF-1080 | 1080P 4 x TVI/CVI/AHD video+1 ch reverse RS485 data;FC 20km;Transmitter |
PG-4V1D-RF-1080 | 1080P 4 x TVI/CVI/AHD video+1 ch reverse RS485 data;FC 20km;Receiver |
PG-4V-TF-1960 | 1960P 4 x TVI/CVI/AHD video;FC 20km;Transmitter |
PG-4V-RF-1960 | 1960P 4 x TVI/CVI/AHD video;FC 20km;Receiver |
PG-4V1D-TF-1960 | 1960P 4 x TVI/CVI/AHD video+1 ch reverse RS485 data;FC 20km;Transmitter |
