small industrial machine series automatic Liquid blister packing machine for machine production
Features:
2 Imported controlling system is adopted; also it can be equipped with detecting and rejection function device (Omron Sensor) for number of medicines according to the user’s requirement. It adopts imported frequency inverter.
4 It can be optional equipped with photocell correction device, imported stepper motor traction and image- character register to optimize packing grade
5 The machine is suitable for industries of foodstuff, medicine, medical instruments, hardware, electronics and etc for packing
Diagram
The features of lquid filling
1. It adopts plunger type metering pump for filling,it is high in precision, the structure of the pump is easy to install and uninstall, and convenient for cleaning and sterilizing.
2. PLC control system, color touch screen display.
3.The filling head has the anti- dropping device
4. The filling precision is 05%, the filling volume is 5-25ml( can be customized)
5. The frame of the machine and contact parts with material are bothmade from stainless steel, it meets with the GMP COMPLETELY.
Configuration list
|
Punches frequency |
10-35times/min |
|
Production capacity |
1200-4200plates/hour( two plates one time) |
|
Max. forming area and depth |
130*100(standard thickness≤15mm) Max. depth 26mm |
|
Stroke range |
50-120mm( can be designed as per user’s required) |
|
Standard plate size |
80*57mm ( can be designed as per user’s required) |
|
Clean compressed air |
0.4/0.6Mpa |
|
Air compressed capacity |
≥0.3m3/min |
|
Total power supply |
380V 50HZ 3.8kw |
|
Main power |
1.5KW |
|
PVC hard film |
(0.15/0.5)*150mm |
|
PTP Aluminum film |
(0.02/0.035)*150mm |
|
Dialysis paper |
(0.02/0.035)*150mm |
|
Mould cooling |
Tap water or recycling water |
|
Overall dimension |
2315*635*1405mm |
|
Net Weight |
820KG |
|
Gross Weight
|
890KG |
|
Overall Dimension |
2500*800*1780mm |
|
Noise |
<75dB |
