automatic liquid Blister Packing Machine is a cost-effective and well-known machine for small industrial machine
Product Description
Applications:
It is suitable for capsule, tablet, big honey pill, candy, liquid, paste, one injector as well as irregular shape
AL-PVC, paper-plastic composite and ALU-ALU sealing packaging in pharmaecutical, healthcare, food, cosmetics industry etc.
Technical specifications
|
Cutting Frequency (Times/min) |
20-40 |
|
Capacity(Blister/h) |
2400 (According To Standard Plate 80×57 Can Calculate The Max Capacity) |
|
Max forming area and depth(mm) |
80×100×26 (Standard 70×90×14) |
|
Stroke (mm) |
20-100 (Can Be Manufactured As User's Requirements) |
|
Air Pressure(MPa) |
0.4-0.6 |
|
Standard Plate (mm) |
80×57 (Can Be Manufactured As User's Requirements) |
|
Total Power |
380V/220V 50Hz 1.8kw |
|
Main motor power (kw) |
0.75 |
|
PVC hard pieces(mm) |
0.15-0.5×80 |
|
PTP Aluminum Foil (mm) |
0.02-0.035×80 |
|
Dialysis Paper (mm) |
50-100g×80 |
|
Mould Cooling |
Tap water or recycle water |
|
Overall Dimensions (mm) |
1400×460×950 (L×W×H) |
|
Weight (kg) |
450 |
Samples:
