ER70S-2
AWS A5.18 ER70S-2
Description：
ER70S-2 is a premium wire for welding on all grades of mild and carbon steels, producing quality welds with minimal porosity. It is a triple deoxidized wire (Zirconium, Titanium, and Aluminum) making it an excellent choice for welding over rust and mill scale. Used for carbon steels and alloy steels with 500MPa tensile strength structures welding, and high speed welding of sheet plates and pipelines.
Diameters:
0.8mm, 0.9mm,1.0mm,1.2mm,1.4mm, 1.6mm.
Typical Mechanical Properties:
Tensile strength(MPa): |
520 |
Yield strength(MPa): |
440 |
Elongation(%): |
29 |
Impact values(≥27J/-20℃): |
52 |
Typical Chemical Compositon:
C |
Mn |
P |
S |
Si |
Ti |
Al |
Zr |
Cu |
V |
0.08 |
1.32 |
0.010 |
0.008 |
0.68 |
0.10 |
0.09 |
0.11 |
-- |
-- |
Welding Current:
Diameter(mm) |
0.8 |
1.0 |
1.2 |
1.6 |
|
Current/A |
F/H |
50-200 |
80-250 |
100-360 |
170-390 |
Current/A |
V/OH |
50-140 |
80-160 |
80-220 |
-- |
Note:
1. Insensitive to impurities (water, oil, rust, etc) on weld piece
2. 2. Shield gas: 80%Ar + 20% CO2.
3. Gas speed: 15-25L/Min
4. Tig rods ER70S-2 1.6mm, 2.0mm, 2.4mm, 3.2mm available
ER80S-D2
AWS A5.28 ER80S-D2
Description：
ER80S-D2 is a low alloy copper-coated tig rod with 0.5% Mo content designed for welding low-alloy steels with high tensile strength and creep resistance. It shows good impact strength at low temperatures and suitable for pipelines and pressure vessels with operating temperatures of about 500°C. It will also find applications for the repair of medium strength steel castings
Diameters:
1.2mm
Typical Mechanical Properties:
Tensile strength(MPa): |
720 |
Yield strength(MPa): |
610 |
Elongation(%): |
27 |
Impact values(≥27J/-20℃): |
76 |
Typical Chemical Compositon:
C |
Mn |
P |
S |
Si |
Mo |
Cu |
0.08 |
1.90 |
0.010 |
0.008 |
0.70 |
0.50 |
0.15 |
Welding Current:
Diameter(mm) |
0.8 |
1.0 |
1.2 |
1.6 |
|
Current/A |
F/H |
50-200 |
80-250 |
100-360 |
170-390 |
Current/A |
V/OH |
50-140 |
80-160 |
80-220 |
-- |
Note:
1. Rusty, water, oil and other impurity should be cleaned before welding.
2. Shield gas: 80%Ar+20% CO2.
3. Gas speed: 15-25L/Min
4. Tig rods ER80S-D2 1.6mm, 2.0mm, 2.4mm, 3.2mm available
