E71T-GS
AWS A5.20 : E71T-GS
AWS A5.36 : E71T14S-AZ-CS3
ISO 17632-A : T42 Z Z V N 1
Description：
E71T-GS is an all positional, self-shield flux cored wire suitable for single pass welding, can be used vertical down welding. With good welding properties, like less spatter, stable arc, low fume, easy slag removal and excellent bead appearance. Used to weld carbon steel sheet structures.
Diameters: 0.6mm, 0.8mm, 0.9mm, 1.0mm, 1.2mm.
Typical Mechanical Properties:
Tensile strength(MPa): |
530 |
Yield strength(MPa): |
-- |
Elongation(%): |
-- |
Typical Chemical Compositon:
C |
Mn |
P |
S |
Si |
Ni |
Cr |
Mo |
Cu |
0.09 |
0.95 |
0.025 |
0.014 |
0.22 |
-- |
-- |
-- |
-- |
Welding Current:(DC-)
Diameter(mm) |
0.8 |
0.9 |
1.0 |
|
Current/A |
80-150 |
80-150 |
80-150 |
|
Voltage/V |
15-20 |
15-20 |
15-20 |
|
Note:
1.Rusty, oil stains, water and other impurity on the weld parts must be cleaned before welding.
2. Stock in dry environment, please use up in short time once opened.
E71T-11
AWS A5.20 E71T-11
EN ISO17632-A-T42 ZZZ N 1
Description：
E71T-11 is an all positional, self-shield flux cored wire suitable for multipass welding, can be used vertical down welding. With good welding properties, like less spatter, stable arc, low fume, easy slag removal and excellent bead appearance.
Diameters:
0.6mm, 0.8mm, 0.9mm, 1.0mm, 1.2mm.
Typical Mechanical Properties:
Tensile strength(MPa): |
545 |
Yield strength(MPa): |
455 |
Elongation(%): |
22.5 |
Typical Chemical Compositon:
C |
Mn |
P |
S |
Si |
Ni |
Cr |
Mo |
Cu |
0.08 |
1.21 |
0.024 |
0.017 |
0.25 |
-- |
-- |
-- |
-- |
Welding Current:(DC-)
Diameter(mm) |
0.8 |
0.9 |
1.0 |
|
Current/A |
80-150 |
80-150 |
80-150 |
|
Voltage/V |
15-20 |
15-20 |
15-20 |
|
Note:
1.Rusty, oil stains, water and other impurity on the weld parts must be cleaned before welding.
2. Stock in dry environment, please use up in short time once opened.
