ENi-CI
AWS A5.15 ENi-CI
GB/T10044 EZNi-1
Description：
A pure nickle electrode designed to weld normal grades cast irons. The weld metal is soft and easily machinable, deposition is performed on cold or slightly preheated material. It is suitable for joining cast irons for the rectification of casting and repairing of broken parts. Used to weld thin parts of cast irons and repair broken parts.
Diameters:
2.5mm, 3.2mm, 4.0mm, 5.0mm.
Typical Chemical Compositon:
C |
Mn |
Si |
S |
Fe |
Ni |
others |
≤2.0 |
≤1.0 |
≤2.5 |
≤0.03 |
≤8.0 |
≥90 |
≤1.0 |
Welding Current:(AC/DC+)
Diameter(mm) |
2.5 |
3.2 |
4.0 |
5.0 |
|
Current/A |
-- |
95-120 |
150-180 |
190-220 |
|
Note:
1.The electrodes must be baked 1 hours in 150℃ before using.
2.Hammer the bead can relieve strength of weld parts to avoid crack..
ENiFe-CI
AWS A5.15 ENiFe-CI
GB/T10044 EZNiFe-1
Description：
A nickel-iron type electrode designed to weld normal grades cast irons and joint them to steel. It has very good current-carrying capacity and the weld metal is stronger and more resistant to solidification cracking than other nickel type electrodes . Used for the repairing of high strength gray cast iron and nodular cast irons.
Welding Position:
Diameters:
2.5mm, 3.2mm, 4.0mm, 5.0mm.
Typical Chemical Compositon:
C |
Mn |
Si |
S |
Cu |
Ni |
Fe |
1.17 |
1.2 |
0.80 |
0.003 |
0.01 |
Bal |
54 |
Welding Current:(AC/DC+)
Diameter(mm) |
2.5 |
3.2 |
4.0 |
5.0 |
|
Current/A |
-- |
95-120 |
150-180 |
190-220 |
|
Note:
The electrodes must be baked 1 hours in 150℃ before using.
