Ultrapure Water Treatment Electrodeionization 5T/ Chinese Brand EDI Manufacturer

Ultrapure Water Treatment Electrodeionization 5T/ Chinese Brand EDI Manufacturer thumbnail-1
Ultrapure Water Treatment Electrodeionization 5T/ Chinese Brand EDI Manufacturer thumbnail-2
Ultrapure Water Treatment Electrodeionization 5T/ Chinese Brand EDI Manufacturer thumbnail-3
Ultrapure Water Treatment Electrodeionization 5T/ Chinese Brand EDI Manufacturer thumbnail-4
Ultrapure Water Treatment Electrodeionization 5T/ Chinese Brand EDI Manufacturer photo-1
Ultrapure Water Treatment Electrodeionization 5T/ Chinese Brand EDI Manufacturer photo-2
Ultrapure Water Treatment Electrodeionization 5T/ Chinese Brand EDI Manufacturer photo-3
Ultrapure Water Treatment Electrodeionization 5T/ Chinese Brand EDI Manufacturer photo-4
US$ 793.00 - 2,000.00 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
CY-Water
Place of Origin:
China
Model Number:
CY-RO-40000 liter -H
Contact Supplier Request Quote Chat Now
Shanghai Chongyang Water Treatment Equipment Co.,ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name CY-Water
Place of Origin China
Model Number CY-RO-40000 liter -H

Product Name: Ultrapure water treatment Electrodeionization 5T/ Chinese brand EDI  Manufacturer
Full range of EDI Module Stack Products:EDI Module Feature:1.The product series is complete,and the flow of single EDI Membrane is 10L/H--5000L/H; 1)The system have no circulation of concentrated water ,no add salt ,electrodeless water discharge ,easy construction;2)The technology that concentrated water resin filled improve moving velocity of ions,low energy consumption;3)Layering technology of fresh water make non-conductive ions to migrate, the water quality is better;4)Large channel partition and special resin treatment technology have strong anti pollution ability;5)Special seal technology and good performance EDI Membrane can prolong  lifetime ;8)Standardized product process ,low cost of maintenance and training cost .

Ultra small EDI Module stack with power supply Ultra small EDI Module with power supply,innovative micro EDI Stack with power supply is successful for customer’s use , and it is impossible for equipment integration of equipment . It is suitable for laboratory purified water ,small and ultra small pure water system .Ultra small EDI Membrane stock The ultra small EDI Membrane stock is suitable for below 200L/H small device . The newest developed YKF Series adopt 1st & 2nd deionization technology ,the water quality can be up to 15-18 MΩ•cm. Micro EDI Membrane StockThe laboratory type EDI Module ,the flow is 10-20L/H with micro flow , small volume ,stable outlet quality .


Module YKF
Min water yield
L/H
Normal water yield
L/H
Max water yield
L/H
Working Voltage
DC V
Working Current
DC A
Size
L
W
H
YKF-10
8
10
20
10-30
0.5-2
50
165
380
YKF-50
10
50
80
10-50
0.5-2
75
165
380
YKF-100
50
100
150
10-50
0.5-2
95
165
380
YKF-150
100
150
200
10-50
0.5-2
115
165
380
YKF-200
150
200
250
10-50
0.5-2
135
165
380
YKF-250
200
250
300
10-50
0.5-2
155
165
380
YKF-300
250
300
350
10-50
0.5-2
175
165
380
YKF-500
300
500
700
10-50
2-5
160
295
670
YKF-1000
500
1000
1500
30-70
2-5
235
295
670
YKF-2000
1500
2000
2500
60-140
2-5
385
295
670
YKF-3000
2500
3000
3500
90-210
2-5
535
295
670
YKF-4000
3500
4000
4500
120-280
2-5
685
295
670
YKF-5000
4500
5000
5500
250-400
2-5
800
295
670


Company Name: Shanghai ChongYang Water Treatment Equipment CO.,LTD

Email : Sales@cy-waterequipment.com

Phone:+86 15900488030

Http://


Product Tags: ion pure edi , ionpure edi modules , edi ionpure
