PD194Z-9HY 3 Phase Multifunction Harmonic Monitoring Digital Panel Meter
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
1993
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PZ195U-DK1 LED Digital Single Phase Embedded dc Volt Energy MeterNegotiableMOQ: 1 -
Digital 3 Phase Panel Mounted Kwh MultimeterNegotiableMOQ: 1
-
3 Phase Multifunction Analog Output Electric Power Meter Digital MultimeterNegotiableMOQ: 1
-
LCD Display Rs485 3 Phase Digital Voltage Electric Power MeterNegotiableMOQ: 1
-
LNF56 Multi-functional Harmonic Analysis Voltage Current Frequency MeterNegotiableMOQ: 1
Product Description
Product Name: PD194Z-9HY 3 phase multifunction harmonic monitoring digital panel meter
This series of multi-function power meters support all-parameter measurement, bi-directional energy metering, four quadrant reactive metering and harmonic analysis. they can be connected to power monitoring system and energy management system to realize remote data monitoring.
Technical parameters
Accuracy |
Voltage, current: 0.2%; power: 0.5%, frequency: ±0.01HZ;Active energy:0.5s |
|
Data update rate |
1s |
|
signal Input |
Rated current |
AC 1A,5A |
Rated voltage |
AC 100V,3800V |
|
Overload |
Continuous:1.2In,instantaneous:10In/5s Continuous:1.2Un,instantaneous:2Un/10s
|
|
Energy consumption |
≤0.1VA |
|
Fequency |
45~65HZ |
|
Communication |
RS485 interface |
Modbus-RTU protocol, baud rate up to 9600bps |
Energy pulse |
Optocoupler isolation ,pulse width 80ms±20% |
|
Digital Input |
Optocoupler isolation ,passive dry contact |
|
Relay Output |
Contact capacity AC250V/5A or DC 30V/5A |
|
Auxiliary power supply |
working range |
AC/DC 80~270V |
Energy consumption |
≤5VA |
|
Environment condition |
working temperature |
-10~55℃ |
storage temperature |
-25~70℃ |
|
Relative humidity |
≤93%RH |
|
Altitude |
≤2500m |
|
Safety |
Insulation |
Signal power supply output terminal to case resistance ≥100MΩ |
Withstand voltage |
power supply，input and output ≥2kv |
|
Protection level |
IP54 |
Related Products
Application
■ Smart equipment
■Intelligent building
■Public facility
■Industrial and mining enter enterprise
■Panel Meter
■Intelligent building
■Public facility
■Industrial and mining enter enterprise
■Panel Meter
