Isolated Single Output DC/DC Converters 4:1, 2:1 Isolated DC/DC Converters 50.8*50.8
The rated output power of TP25DG converters is 25W, the outline dimensions is 50.8x50.8x11.2, 2:1 and 4:1 wide input voltage range, the voltage range is 9V-18V,18V-36V,36V-72V,9V-36V and 18V-72VDC.The accuracy of the converter can reach ±1%, it can be widely used in telecommunications, railway transportation, instrument and etc.
we,TOPPOWER can produce:
0.1W-40W DC-DC converters,3W-30W AC-DC converters,(SIP/DIP/SMD)
15W-1200W Enclosed /Open frame/DIN RAIL type AC-DC Switching Power supply,
TOPPOWER quality : ISO9001:2015, IATF16949:2016
Part Number |
Input Voltage |
Output |
|||
voltage（VDC) |
Voltage（VDC) |
||||
Rated |
Range values |
||||
|
TP25DG12S03
|
12(2:1) |
9-18 |
3.3 |
||
TP25DG12S05 |
12(2:1) |
9-18 |
5 |
||
TP25DG12S12 |
12(2:1) |
9-18 |
12 |
||
TP25DG12S15 |
12(2:1) |
9-18 |
15 |
||
TP25DG12S24 |
12(2:1) |
9-18 |
24 |
||
TP25DG12D05 |
12(2:1) |
9-18 |
±5 |
||
TP25DG12D12 |
12(2:1) |
9-18 |
±12 |
||
TP25DG12D15 |
12(2:1) |
9-18 |
±15 |
||
TP25DG24S03 |
24(2:1) |
18-36 |
3.3 |
||
TP25DG24S05 |
24(2:1) |
18-36 |
5 |
||
TP25DG24S12 |
24(2:1) |
18-36 |
12 |
||
TP25DG24S15 |
24(2:1) |
18-36 |
15 |
||
TP25DG24S24 |
24(2:1) |
18-36 |
24 |
||
TP25DG24D05 |
24(2:1) |
18-36 |
±5 |
||
TP25DG24D12 |
24(2:1) |
18-36 |
±12 |
||
TP25DG24D15 |
24(2:1) |
18-36 |
±15 |
||
TP25DG48S03 |
48(2:1) |
36-72 |
3.3 |
||
TP25DG48S05 |
48(2:1) |
36-72 |
5 |
||
TP25DG48S12 |
48(2:1) |
36-72 |
12 |
||
TP25DG48S15 |
48(2:1) |
36-72 |
15 |
||
TP25DG48S24 |
48(2:1) |
36-72 |
24 |
||
TP25DG48D05 |
48(2:1) |
36-72 |
±5 |
||
TP25DG48D12 |
48(2:1) |
36-72 |
±12 |
||
TP25DG48D15 |
48(2:1) |
36-72 |
±15 |
||
TP25DG24S05W |
24(4:1) |
9-36 |
5 |
||
TP25DG24S12W |
24(4:1) |
9-36 |
12 |
||
TP25DG24S15W |
24(4:1) |
9-36 |
15 |
||
TP25DG24S24W |
24(4:1) |
9-36 |
24 |
||
TP25DG24D05W |
24(4:1) |
9-36 |
±5 |
||
TP25DG24D12W |
24(4:1) |
9-36 |
±12 |
||
TP25DG24D15W |
24(4:1) |
9-36 |
±15 |
||
TP25DG48S05W |
48(4:1) |
18-72 |
5 |
||
TP25DG48S12W |
48(4:1) |
18-72 |
12 |
||
TP25DG48S15W |
48(4:1) |
18-72 |
15 |
||
TP25DG48S24W |
48(4:1) |
18-72 |
24 |
||
TP25DG48D05W |
48(4:1) |
18-72 |
±5 |
||
TP25DG48D12W |
48(4:1) |
18-72 |
±12 |
||
TP25DG48D15W |
48(4:1) |
18-72 |
±15 |
||
