IEC61000-4-4 Capacitive coupling clamp
1. Introduction
The capacitive coupling clamp is designed to work with electrical fast transient/ burst generator (EFT/B), The coupling method using the clamp is used for tests on lines connected to signal port, control port and power port. The performance of clamp is fully compliant with IEC61000-4-4.
2. Specification
Coupling capacitor | 100~1000pF |
Insulation ability | >5KV |
Dimension | 1050*140*110 |
3. Figure
