PT131-50MPA-M14-K SAND pressure transmitter
- 10000 Piece / Pieces per Month
- shenzhen
- T/T L/C
- 5 days
Product Details
Brand Name: | SAND | Place of Origin: | China | Model Number: | PT131 |
Usage: | Pressure Sensor | Theory: | Other, pressure sensor | Output: | Digital Sensor |
Product Description
Mainly used for high-precision pressure and temperature measurement. Pressure measurement range from 0~5~200MPa ;Measurement accuracy: ±0.2% FS, ±0.5% FS; Temperature drift: ≤ 0.15MPa/100 ℃; Output: 3.0 mV/V, 3.33mV/V; Probe temperature: 400 ℃;Temperature sensor: E,J,K,S,Pt100, etc. This series of products using all stainless steel frame, durable, nice; six core-level military connectors, reliable connection, signal stability, the same point measuring pressure and temperature .
1. Pressure range: 0~5MPa~200MPa ;
2. Accuracy: ±0.5% FS, ±1.0% FS;
3. Working Power: 6~12V DC;
4. Output:
PT131 Series: 2.0 mV/V, 2.5 mV/V;
PT1316 Series: 3.0 mV/V, 3.33mV/V;
5. Probe temperature: 400 ℃;
6. Temperature drift: ≤ 0.3MPa/100 ℃;
7. Electrical connections:
PT131 Series: 5PIN;
PT1316 Seerise: 6PIN ;
8. Mechanical connection: 1/2 "-20UNF etc. (Optional) ;
9. Temperature sensor: E,J,K,S,Pt100, etc. (Optional) ;
10.Preservative wear-resistant coating:
Apply to the high concentration of rough medium pressure measurement, Can increase life of three to five times (Optional);
11.Special requirements can be customized, delivery time from 7 to 15 working days.
