PTF1316B explosion-proof Type Melt Pressure Transmitte

Introduction
This kind of pressure transmitters are explosion-proof and safe type. It is suitable for combustable and explosive high-risk situations. It is up to the mustard of ExiaIIBt6/ExiaIICT6. The transmitters adopt low-power consumption components which coordinate with security wiring design.

Model Description

Performance indicators

1  Intrinsically safe by "ExiaIIBT6" and "ExiaIICT6" explosion-proof certification;
2  Adopting safe circuit design;
3  Stainless steel shell, beautiful rugged and durable;
4  1/2 "-20, M14 x 1.5, M18 x 1.5, M20 x 1.5, M22 x 1.5 a variety of mounting dimensions to      facilititate the users to select;
5  Accuracy: ± 0.5% FS, ± 1.0% FS (default);
6  Output signal: 0 ~ 5v, 1 ~ 5v, 4 ~ 20mA;
7  Corrosion resistant coating to extend the service life of 3 to 5 times; (optional)
8  Thermometric Config:
    Thermocouple: E, J, K type, etc.,
    Thermal resistant: Pt100 etc. (Optional)
