APPLICATION
Ø Plate Frame Pressurized Type Oil Purifier Series PL is specially designed for power station, electricity factory, power electrical substation of industrial and mining enterprise, lube oil depot, tractor station, petroleum, chemical engineering, metallurgy, national defense industry, etc, filtering water content and impurities of transformer oil, turbine oil, engine oil, cooking oil, EP gear oil, machine oil, diesel oil, hydraulic oil and as well as filtering edible oil while using stainless steel plates. It’s a great choice as pre-treatment equipment prior to high vacuum oil purifier machines.
Ø Plate Frame Pressurized Type Oil Purifier Series PL is made up of filtering bed, boosting type oil pump and rough filter. There are filtering media, such as filtering paper or filtering fuse, installed between the steel filter board and filter plate that will be fixed to form a single filtering room under the pressure of the packing device. The filtering paper or filtering fuse packed between the filter board and filter plate will play a role of filtering.
Ø Special boosting type oil pump has strong suction ability and make the machine to be used in more oil types.
Ø Low noise, Quick and convenient to replace filter paper, Simple structure, Easy to use, Lower operation cost
Ø Due to the limitation of gear structure and installation structure, this machine is not suitable for the cleaning of high viscosity fluids. In regard to the non-lubricating oils like gasoline and kerosene (paraffin), special raw materials and motors need be equipped.
Ø If the oil’s viscosity is a little high, the oil should be heated firstly by the extra heaters, or choose our high vacuum oil purifier machines directly. If the oil is too dirty, customer can adopt sedimentary method to remove some particles firstly, then use PL Series.
TECHNICAL PARAMETER
Model |
PL-30 |
PL-50 |
PL-100 |
PL-125 |
PL-150 |
PL -200 |
PL-300 |
||||||
Flow Rate |
L/min |
30 |
50 |
100 |
125 |
150 |
200 |
300 |
|||||
Working Pressure |
MPa |
0 - 0.5 |
|||||||||||
Filtering Area |
≥m2 |
0.3 |
0.39 |
1.3 |
1.54 |
1.89 |
2.01 |
3.1 |
|||||
Board Frame Size |
mm |
180×180 |
280×280 |
||||||||||
Press Manner |
Screw Manually |
||||||||||||
Filter Frame Number |
11 |
13 |
10 |
12 |
14 |
18 |
23 |
||||||
Filter Plate Number |
12 |
14 |
11 |
13 |
15 |
19 |
24 |
||||||
Gear Oil Pump |
Flow |
L/min |
>30 |
>50 |
>100 |
>125 |
>150 |
>200 |
>300 |
||||
|
Safe Pressure |
MPa |
0.6 |
|||||||||||
Power supply |
380V, 3Phase, 50hz (or as per user’s option) |
||||||||||||
Viscosity (mm2/S) |
≤46 |
||||||||||||
Motor |
Power |
kW |
1.1 |
3 |
4 |
5.5 |
|||||||
Rotation Speed |
r/min |
1400 |
1420 |
1440 |
|||||||||
Filtering precision |
≤1 ~ 5 µm |
||||||||||||
Noise dB(A) |
≤ 55 |
||||||||||||
Filter paper size |
mm |
185*190 |
285*290 |
||||||||||
Diameter |
Inlet |
mm |
25 |
25 |
32 |
32 |
44 |
44 |
50 |
||||
outlet |
mm |
32 |
32 |
44 |
44 |
50 |
50 |
65 |
|||||
Dimension |
Length |
mm |
700 |
750 |
1120 |
1200 |
1320 |
||||||
Width |
mm |
300 |
500 |
||||||||||
Height |
mm |
720 |
920 |
1000 |
|||||||||
Weight |
Kg |
76 |
115 |
180 |
250 |
270 |
300 |
330 |
|||||
