Foundation drill rig type casing oscillator hydraulic type 1300mm connect on bauer bg28 drill rig with euro tier5 emissions power pack
Foundation drill rig type hydraulic casing oscillator 1200mm connect on san-y sr285 drill rig with euro tier5 emissions diesel engine power pack
Short typer casing oscillator 1500mm connect on soilmec drill rig with euro tier5 emissions diesel engine power pack for cased bored pile foundation work
Short version drill rig casing oscillator connected on lieb-herr LB28 rotary drill rig for cased piling foundation work
1300mm hydraulic casing oscillator connected on bau-er bg28 rotary drill rig for cased bored pile foundation work
Foundation drill rig casing oscillator 1300mm used for drop down and pull out double wall casing during secant pile foundation work
Foundation drill rig casing oscillator 1200mm used for drop down and pull out double wall casing during secant pile foundation work
Foundation drill rig casing oscillator 1500mm used for drop down and pull out double wall casing during secant pile foundation work
1800mm hydraulic casing oscillator connected on bau-er bg28 rotary drill rig for cased bored pile foundation work
2000mm hydraulic casing oscillator connected on bau-er bg28 rotary drill rig for cased bored pile foundation work
The short hydraulic casing oscillators have been desinged in accordance the latest technical , extremely sutrdy construction guarantee wirth-while
By means of easily exchangeable reducer pieces,the casing oscillator can be converted ,within a few mimutes,to a smaller diameter , the collar opens uniformly and enanbles unproblematic inertion of the casing with the cutting shoe , attachment at the excavator itiself is torque rigid and guarantees the full transmission of the full rotaring movement to to the casing
The design and construction of the casing oscillator is based on the experience of many years of cooperation with companies specializaing in pile foundation tianjin huachang xingye technology co ltd
The casing oscillators can easily be adapted on site for use with smaller casing diameters by appropriate sets of reduction inserts. The hydraulic power supply is provided by the on-board hydraulic system of the drilling rig. As an alternative, the casing oscillator can also be powered by an external hydraulic power pack. It can then be operated by remote control independently from the drilling rig.
MODEL： |
BCG1300D |
REMARK |
OSCILLATE DIAMETER (mm) |
600～1300 |
|
MAX LIFT FORCE (kN) |
1800 |
|
OSCILLATE ANGEL (°) |
18° |
|
TORQUE (KN·m) |
1950 |
|
STOKE（mm） |
450 |
|
CLAMP FORCE（kN） |
1600 |
|
OVER SIZE(L×W×H)(mm) |
3300×2350×1600 |
|
WEIGHT (T) |
12 |
2,specification of power pack
MODEL： |
DL160 |
REMARK |
DIESEL ENGINE MODEL： |
QSB4.5-C130 |
|
DIESEL ENGINE POWER kW |
100 |
|
DISCHARGE l/min |
150 |
|
OPERATION PRESSURE：MPa |
25 |
|
OIL TANK CAPACITY L |
800 |
|
OVERSIZE (L×W×H)(mm) |
3000×1900×1700 |
|
WEIGHT (kg) |
2500 |
NOT INCLUDE HYDRAULIC OIL |
