Help CenterỐng Vách Thép Phục D800mm vụ Khoan Nhồi Casing 840mm/760mm
Related Products
-
Gầu Khoan đá D800 for Cọc 800mmUS$ 1000 - 3000MOQ: 1 Piece -
Gầu Cắt Vành D1000MM for Cọc 1000mmUS$ 1000 - 3000MOQ: 1 Piece
-
Sell 1000mm Core Barrel With Round Shank Chisel Used for Bored Pile Foundation WorkUS$ 1000 - 3000MOQ: 1 Piece
-
Sell 8inch Roller Cutter Used for RCD Air Lift Reverse Circulation Drill in Pile Foundation WorkUS$ 1000 - 3000MOQ: 1 Piece
-
Vành Cắt Răng Quả na D1500MM Cọc 1500mmUS$ 1000 - 3000MOQ: 1 Piece
Ống vách thép phục d800mm vụ khoan nhồi Casing 840mm/760mm
Ống vách thép phục d1000mm vụ khoan nhồi Casing 1000mm/9200mm
Ống vách thép phục d1200mm vụ khoan nhồi Casing
Ống vách thép phục d1500mm vụ khoan nhồi Casing
Ống vách thép phục d200mm vụ khoan nhồi Casing 840mm/760mm
Ống vách thép phục d2500mm vụ khoan nhồi Casing
Đường kính (Diameter): từ Φ290 - Φ2.500(mm)
Chiều dài (Length):theo yêu cầu(mm)
Chiều rộng (Width):theo yêu cầu(mm)
Chiều dày (Thichness):
double wall casing with screw joint
Casing joints and pipes for pile protection of collapsing. Casing joints are composed of one male half joint and one female joint welded at each end of casing pipe for easy pipe connection. Joints coupling supplied with conical screw type for single and double wall casing.size:600mm-2500mm
Double Wall Casings – Screw type, Diameter 1000/920 mm, Length: 2 m
Double Wall Casings – Screw type, Diameter 1000/920 mm, Length: 3 m
Tianjin huachang xingye technologyc o ltd
Whatsapp 008618902059907 email info@tjdrilling.com
| D1/D2 | 1m | 2m | 3m | 4m | 5m | 6m | a1 | a2 | t2 | Bolts |
| (mm) | Weight(kg) Parts Number | (mm) | (mm) | (mm) | (Nos) | |||||
| 620/540 | 403 | 739 | 1074 | 1411 | 1747 | 2081 | 12 | 8 | 40 | 8 |
| 750/670 | 492 | 902 | 1311 | 1722 | 2131 | 2540 | 12 | 8 | 40 | 10 |
| 880/800 | 585 | 1069 | 1552 | 2036 | 2520 | 3005 | 12 | 8 | 40 | 10 |
| 1000/920 | 669 | 1221 | 1773 | 2328 | 2877 | 3429 | 12 | 8 | 40 | 10 |
| 1180/1100 | 844 | 1580 | 2316 | 3052 | 3787 | 4522 | 16 | 8 | 40 | 12 |
| 1200/1120 | 872 | 1620 | 2370 | 3120 | 3870 | 4620 | 16 | 8 | 40 | 12 |
| 1300/1220 | 933 | 1746 | 2558 | 3372 | 4184 | 4996 | 16 | 8 | 40 | 12 |
| 1500/1400 | 1433 | 2628 | 3817 | 5009 | 6210 | 7393 | 20 | 10 | 50 | 12 |
| 1800/1700 | 1730 | 3166 | 4602 | 6038 | 7474 | 8910 | 20 | 10 | 50 | 16 |
| 2000/1880 | 2450 | 4280 | 6110 | 7940 | 9770 | 11600 | 20 | 15 | 60 | 12 |
| 2200/2080 | 2700 | 4720 | 6740 | 8760 | 10780 | 12800 | 20 | 15 | 60 | 12 |
| 2500/2380 | ||||||||||
Send Inquiry to This Supplier
