0.6/1KV XLPE Insulated Power Cable
Application
Suitable for power transmission and distributuin line with rated voltage up to and including 0.6/1KV.
U0—The rated power-frequency voltage between conductor and earth,for which the cable designed:
U-- The rated power-frequency voltage between conductors,for which the cable designed
The ing temperature of conductor: 90°C.
Short-circuit temperature (lasting no longer than 5s ): ≤250°C for XLPE insulated cable.
Model and Name
|
Model |
Name |
|
|
Cu |
AL |
|
|
YJV
|
YJLV
|
XLPE insulated PVC sheathed power cable
|
|
ZR-YJV
|
ZR-YJLV
|
XLPE insulated PVC sheathed flame-retardant power cable
|
|
YJV22
|
YJLV22
|
XLPE insulated PVC sheathed steel tape armored power cable
|
|
ZR-YJV22 |
ZR-YJLV22 |
XLPE insulated PVC sheathed steel tape armored flame-retardant power cable |
YJV Cu/XLPE/PVC
YJV22 CU/XLPE/steel tape armore/PVC
Specification of cable
|
No.of cores |
Cu |
Al |
||
|
YJV,ZR-YJV |
YJV22,ZR-YJV22 |
YJLV,ZR-YJLV |
YJLV22,ZR-YJLV22 |
|
|
1 2 3 4 5 3+1 3+2 4+1 |
1.5~500 1.5~300 1.5~300 1.5~300 1.5~300 4~300 4~300 4~300 |
10~500 4~240 2.5~240 2.5~240 2.5~240 4~240 4~240 4~240 |
4~500 4~300 4~300 4~300 4~300 6~300 6~300 6~300 |
10~500 4~240 4~240 4~240 4~240 6~240 6~240 6~240 |
1 conductor 2 insulation 3tape 4 inner covering 5 armour (steel tape, steel wire) 6 filler 7 oversheath
Copper core Plastic insulated fire-resisitant power cable
|
Model |
Name |
Main Application |
|
NH-YJV |
Copper core fire-resisitant XLPE insulated PVC sheathed power cable |
For fixed-laying upon fire-resisitant reqiuirement |
|
NH-YJV22 |
Copper core fire-resisitant XLPE insulated PVC sheathed steel tape armored power cable |
For fire-resisitant fixed-laying ,able to bear larger mechanical forces |
Electrical Property
|
No. |
Property |
PVC insulated |
XLPE insulated |
|
1 |
volume resistivity ρΩ·cm
Working temperature 20°C |
1013 1010 |
- 1010 |
|
2 |
volume resistivity ρΩ·cm
Working temperature 20°C |
36.7 0.037 |
- 3.67 |
Fire-resisitant property
|
Flame temperature °C |
Rated voltage KV |
Combustion time min |
Test request |
|
|
A |
950~1000 |
0.6 |
90 |
Fuse 3A will not break |
|
B |
750~800 |
|||
NH-YJV22
