787/1000G2 Slewing bearing 1000x1250x100mm for stacker track swivel equipment
- 3000 Piece / Pieces per Month
- SHANGHAI
- T/T
- 30 days
- Slewing bearing 1092DBS101y specification 1358X1092X125mm
- 142DBS101Y four point contact ball Slewing bearing 1750x1424x120mm with internal gear
- Double row four point contact ball slewing bearing with teeth 4548.6x3970x187mm for heavy duty industry machine
- Double row ball Slewing/turntable bearing 5014 with size 1143*880*105mm
- 71769/850Y four point contact ball slewing bearig used for heap leach equipment 1120x850x85mm
- 635x425.45x139.7 mm Swivel bearing without gear,used for radial stacker front track equipment.
Product Details
Brand Name: | JHB | Place of Origin: | China | Model Number: | 787/1000G2 |
Feature: | Four Point Contact | Seals Type: | doulbe seal | Outside Diameter: | 1250, |
Bore Size: | 1000, | Gear Options: | Nongeared |
Product Description
787/1000G2 Slewing bearing 1000x1250x100mm for stacker track swivel equipment
787/1000G2 slewing bearing belongs to single row four point slewing bearing without teeth,It consist on inner ring and outer ring and ball with seal. This kind of slewing bearings can support high dynamic loads, transmitting axial and radial forces simultaneously as well as the resulting tilting moments. It is composed of two seat rings. It has compact structure, light weight, and four-point contact between steel ball and arc raceway. It can bear axial force, radial force and overturning moment at the same time. The construction machinery of rotary conveyor, welding manipulator, small and medium-sized crane and excavator can be selected.
787/1000G2 slewing bearing size as following:
Name | 4 point contact ball slewing bearing 787/1000G2 |
Boundary dimension | 1000x1250x100mm |
Outer dia: | 1250 mm |
Inner dia: | 1000 mm |
Height: | 100 mm |
Radial clearance | 0.12-0.28 mm |
Rolling | Ball |
Material | 50Mn |
The delivery time | 30 days after getting the order |
application | stacker track swivel equipment |
Seal | Double seal |
Lubrication | Grease/oil available |
Origin | Luoyang, Henan, China |
Rows Number | Single |
HS Code | 8482109000 |
