Home > Manufacturing & Processing Machinery > Metallic Processing Machinery > Metal Straightening Machinery > Steer Bar Straightening Machine - Type RTZ16-16B/200 Meters per Minute
Steer Bar Straightening Machine - Type RTZ16-16B/200 Meters per Minute
US$ 100 - 45000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
Gangli Machinery
Place of Origin:
China
Model Number:
Type RTZ16-16B
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai, Ningbo, Wuhu
Delivery Detail:
30 days
Related Products
-
Universal Type All-in-one Model Straightening Hoop Bending MachinesUS$ 100000 - 200000MOQ: 1 Unit -
Steel Bar Straightening Machine For Steel Tube For SaleUS$ 2,460 - 3,560MOQ: 1 Set
-
HRE Steel Bar Straightening and Cutter MachineUS$ 300 - 450MOQ: 5 Pieces
-
GTQ5-12 Steel Bar Straightening and Cutting MachineNegotiableMOQ: 1 Set
-
Steel Bar Straightening Cutting Machine YGT4-14 Elegant Design Cheap Price Steel Bar Straightening Cutting MachineNegotiableMOQ: 1 Piece
Brand Name
Gangli Machinery
Place of Origin
China
Model Number
Type RTZ16-16B
Type
Straightener & Cutter
Use
Bar
Certification
ISO 9001:2000
After-sales Service Provided
Engineers available to service machinery overseas
Warranty
1 Year
Weight
7200
Dimension(L*W*H)
40*2*2
Condition
New
Voltage
220
Power(W)
60000
A more advanced type of straightening machine in the market by Gangli Machine, the straightening speed can reach 200m/min or more, and the straightening effect is good, no overturning and no distortion. Interested parties can consult our company.
Technical parameters of LRTZ12-12B three-stage steel straightening machine
| name | unit | Technical Parameters | |||||
| model | LTZ12-12A | LTZ12-12B | LRTZ12-12A | LRTZ12-12B | RTZ12-12A | RTZ16-16B | |
| Straightening steel type | Cold rolled and hot rolled round bar | Cold rolled and hot rolled round bar | Cold-rolled and hot-rolled ribbed bar | Cold-rolled and hot-rolled ribbed bar | Hot rolled ribbed bar | Hot rolled ribbed bar | |
| Straightening diameter | Mm/mm | Φ4-10/12 | Φ4-10/12 | Φ4-12 | Φ4-12 | Φ5-12 | Φ6-16 |
| Straightening speed | Meter/minute (m/min) | 50 | 80 | 80 | 180 | 180 (200) | 180 (200) |
| Predetermined length | Meter (m) | 0.5--99 | 0.8--99 | 1--99 | 1--99 | 1--99 | 1--99 |
| Cut-off error | Millimeter (mm) | ±7 (±2) | ±5 (±2) | ±5 (±2) | ±2 | ±2 | ±2 |
| Length of blanking chute | Meter (m) | 6 | 8 | 8 | 8--12 | 8--12 | 8--12 |
| Length of receiving frame | Meter (m) | 1--12 meters (above 9 meters is optional) | |||||
| control method | A set of controls | Two sets of CNC cycles | Touch screen + PLC | Touch screen + PLC | Touch screen + PLC | Touch screen + PLC | |
| Main Power | KW (kilowatts) | 5.5/7.5 | 15 | 15 | 37 | 37 | 55 |
| Cut off power | KW (kilowatts) | 2.2 | 4 | 4.5 | 5.5 | 5.5 | 7.5 |
| Working area (including pay-off) | Length×width×height | 12×1.5×2 | 15×2×2 | 15×2×2 | 30×2×2 | 30×2×2 | 40×2×2 |
| Weight (approximately) | Kilogram (Kg) | 1500 | 1800 | 8200 | 5200 | 5000 | 7200 |
| Number of traction wheels | only | 6 | 6 | 6 | 10 | 10 | 10 |
| Straightening method | Spin | Spin | Vertical, horizontal + rotation | Vertical + water | vertical | vertical | |
| Speed mode | Single-speed | Two-stage speed | Two-stage speed | frequency conversion | frequency conversion | frequency conversion | |
| Cutting control method | CNC machinery | CNC machinery | Servo Control | Servo Control | Servo Control | Servo Control | |
| Shear length measurement method | Rotation coding | Rotation coding | Rotation coding | ||||
| Unloading rack form | single | single | double | double | double | double | |
| Automatic steel leveling device | Yes | Yes | Yes | ||||
| Φ6 steel bar output | Kilogram (Kg) | 666kg/h | 1000kg/h | 1000kg/h | 2398kg/h | 2398kg/h | 2500kg/h |
| Φ8 steel bar output | Kilogram (Kg) | 1180kg/h | 1900kg/h | 1900kg/h | 4200kg/h | 4200kg/h | 4200kg/h |
| Φ10 steel bar output | Kilogram (Kg) | 1840kg/h | 2950kg/h | 2950kg/h | 6000kg/h | 6000kg/h | 6000kg/h |
| Φ12 steel bar output | Kilogram (Kg) | 7000kg/h | 7000kg/h | 7000kg/h | |||
| Φ14 steel bar output | Kilogram (Kg) | 8000kg/h | |||||
| Φ16 steel bar output | Kilogram (Kg) | 9000kg/h | |||||
| operator | Staff/Unit | 1 | 1 | 1 | 2 | 2 | 2 |
