DW-200(SAPPHIRE) Auto Chemistry Analyzer
Features:
1. 49 Sample positions.
2. 56 Reagent positions.
3. 120 Reaction cuvettes.
4. 200 tests per hour.
5. Probe anti-collision function.
Reaction tray Reagent tray
37℃±0.1℃, real-time monitor 2℃~8℃ cooling for 24 hours.
Mixer Probe Teflon coating
Teflon coating to avoid cross contamination. Liquid level sensor function. Anti-collision function.Reagent
volume real-time detection.
Software Washing Probe
User-friendly software. Independent 4-step washing system.
Overall Performance | Model | BK-200(SAPPHIRE) |
Type | Random, Bench-top, Discrete, Fully automatic | |
Throughput | 200Tests/Hour | |
Analysis Method | End-point, Fixed-time, Rate, Turbidimetry | |
Certification | CE, FDA, ISO9001, ISO14001, ISO13485 | |
Sample & Reagent Unit | Sample Positions | 49 sample positions, including calibration, quality control and emergency |
Reagent Positions | 56 refrigerated reagent positions | |
Sample Volume | 2~70μl (0.1μl stepping) | |
Reagent Volume | R1&R2: 20~350μl (1μl stepping) | |
Sample& Reagent Probe | Liquid level sensor function, anti-collision function | |
Probe cleaning | Automatically wash interior and exterior | |
Reagent tray cooling | 2℃~8℃cooling for 24 hours | |
Reaction Unit | Reaction Time | 10 minutes |
Temperature Control | 37℃±0.1℃, real-time monitor | |
Cuvettes | 120 reusable cuvettes (optical path length 6mm) | |
Mixer probe | After adding reagent and sample, mix immediately | |
Washing | Automatically cuvettes washing | |
Optical System | Light Source | 12V/30W halogen-tungsten lamp, 2000 hours lifetime |
Receiver | 8 precision photo receivers | |
Wavelength Range | 340,405,450,510,546,578,630,700nm | |
Linear Range | 0.000~3.000Abs | |
Calibration and QC | Calibration | One-point, two-point, multi-point, factor, logit-4P, logit-5P, spline |
Quality Control | Inserting quality control at random, with reaction curve checking each test items clearly | |
Software | STAT Function | Emergency samples can be placed in the sample tray at any time |
Computer System | Windows 7/8/10, LIS system available | |
Data Processing | Reaction curve and data display function | |
Others | Power Supply | AC110/220V±10%, 60/50Hz |
Consumption | 300w | |
Package Size(W*D*H) | 1118*728*1151mm | |
Gross Weight | 130kg |
Name | Unit | Quantity |
Sample cup | One | 1 |
Cuvettes | Pack(120 units) | 1 pack |
Reagent Probe | One | 1 |
Sample Probe | One | 1 |
Mixer probe | One | 1 |
Fuse | One | 1 |
Halogen lamp | One | 1 |
