DW-200(SAPPHIRE) Auto Chemistry Analyzer
Features:
1. 49 Sample positions.
2. 56 Reagent positions.
3. 120 Reaction cuvettes.
4. 200 tests per hour.
5. Probe anti-collision function.
Reaction tray Reagent tray
37℃±0.1℃, real-time monitor 2℃~8℃ cooling for 24 hours.
Mixer Probe Teflon coating
Teflon coating to avoid cross contamination. Liquid level sensor function. Anti-collision function.Reagent
volume real-time detection.
Software Washing Probe
User-friendly software. Independent 4-step washing system.
|
Overall Performance |
Model |
BK-200(SAPPHIRE) |
Type |
Random, Bench-top, Discrete, Fully automatic |
|
Throughput |
200Tests/Hour |
|
Analysis Method |
End-point, Fixed-time, Rate, Turbidimetry |
|
Certification |
CE, FDA, ISO9001, ISO14001, ISO13485 |
|
Sample & Reagent Unit |
Sample Positions |
49 sample positions, including calibration, quality control and emergency |
Reagent Positions |
56 refrigerated reagent positions |
|
Sample Volume |
2~70μl (0.1μl stepping) |
|
Reagent Volume |
R1&R2: 20~350μl (1μl stepping) |
|
Sample& Reagent Probe |
Liquid level sensor function, anti-collision function |
|
Probe cleaning |
Automatically wash interior and exterior |
|
Reagent tray cooling |
2℃~8℃cooling for 24 hours |
|
Reaction Unit |
Reaction Time |
10 minutes |
Temperature Control |
37℃±0.1℃, real-time monitor |
|
Cuvettes |
120 reusable cuvettes (optical path length 6mm) |
|
Mixer probe |
After adding reagent and sample, mix immediately |
|
Washing |
Automatically cuvettes washing |
|
Optical System |
Light Source |
12V/30W halogen-tungsten lamp, 2000 hours lifetime |
Receiver |
8 precision photo receivers |
|
Wavelength Range |
340,405,450,510,546,578,630,700nm |
|
Linear Range |
0.000~3.000Abs |
|
Calibration and QC |
Calibration |
One-point, two-point, multi-point, factor, logit-4P, logit-5P, spline |
Quality Control |
Inserting quality control at random, with reaction curve checking each test items clearly |
|
Software |
STAT Function |
Emergency samples can be placed in the sample tray at any time |
Computer System |
Windows 7/8/10, LIS system available |
|
Data Processing |
Reaction curve and data display function |
|
Others |
Power Supply |
AC110/220V±10%, 60/50Hz |
Consumption |
300w |
|
Package Size(W*D*H) |
1118*728*1151mm |
|
Gross Weight |
130kg |
Name |
Unit |
Quantity |
Sample cup |
One |
1 |
Cuvettes |
Pack(120 units) |
1 pack |
Reagent Probe |
One |
1 |
Sample Probe |
One |
1 |
Mixer probe |
One |
1 |
Fuse |
One |
1 |
Halogen lamp |
One |
1 |
