500mW 671nm Single Mode Red Laser for Holography

500mW 671nm Single Mode Red Laser for Holography thumbnail-1
500mW 671nm Single Mode Red Laser for Holography thumbnail-2
500mW 671nm Single Mode Red Laser for Holography thumbnail-3
500mW 671nm Single Mode Red Laser for Holography photo-1
500mW 671nm Single Mode Red Laser for Holography photo-2
500mW 671nm Single Mode Red Laser for Holography photo-3
US$ 3,000 - 11,960 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
CNI
Place of Origin:
Jilin, China
Model Number:
MSL-FN-671
Contact Supplier Request Quote Chat Now
Changchun New Industries Optoelectronics Tech Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Changchun
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name CNI
Place of Origin Jilin, China
Model Number MSL-FN-671
Product Description

It is used in DNA sequencing, flow cytometry, cell sorting, optical instrument, spectrum analysis, interference, measurement, holography, laser printing, chip inspection, physics experiment, etc

Features

Output Power up to 500 mW

TEC cooling system

Lightweight, compact design

Superior beam quality

Single longitudinal mode

Best reliability and lifetime

Coherent length more than 50 m

Applications

DNA sequencing

Flow cytometry

Cell sorting

Optical instrument

Spectrum analysis

Interference measurement

Holography

Physics experiment

　

Specifications for Holography laser 500mW 671nm Single Mode Red Laser Module
Model
MSL-FN-671
Wavelength (nm)
671±1
Operating mode
CW
Output power (mW)
>1, 5, 10, 20, … , 500
Power stability (rms, over 4 hours)
<1%, <3%, <5%
Transverse mode
TEM00
Longitudinal mode
Single
Spectral linewidth (nm)
<0.00001
Coherent length (m)
>50
Noise of amplitude (rms, 1Hz~20MHz)
<1%, typical<0.5%
M2 factor
<1.2
Beam diameter at the aperture (1/e2, mm)
<2.0, typical<1.5
Beam divergence, full angle (mrad)
<1.2
Polarization ratio
>100:1, Vertical±5 degree (Horizontal Optional)
Warm-up time (minutes)
<10
Pointing stability after warm-up (mrad)
<0.05
Beam height from base plate (mm)
27.4
Operating temperature (℃)
15~35
Power supply (90-264VAC)
PSU-H-FDA
Expected lifetime (hours)
10000
Warranty
1 year
Certifications
Packing & Delivery
Company Information

    Changchun New Industries (CNI) founded in 1996, located in Changchun, CHINA, is a leading manufacturer of solid-state and diode laser systems. Our products include green laser, blue laser, yellow laser, red laser, RGB laser, infrared laser, UV laser, single longitudinal mode laser and Q-switched laser systems. CNI lasers are featured with high performance, low cost and excellent laser beam quality, which are specifically designed for OEM, scientific, industrial and instrumentation use. In addition, CNI lasers are ISO-9001, FDA, CE and JQA certified.

    CNI also provides laser components and accessories, we aim to offer customers complete laser solutions for all solid state lasers, diode lasers, laser marking system with our most convenient and rapid service.
