Help CenterHigh Quality 4mm2 dc Solar Cable
Related Products
-
BV,BVR,RV.BLV Different Types of CablesUS$ 0.1 - 10MOQ: 1 Meter -
Overhead Abc Cable Aerial Bundle Cable XLPE InsulationUS$ 1 - 10MOQ: 1 Meter
-
High Quality Factory Supply Aluminum RodUS$ 1 - 5MOQ: 1 Meter
-
Concentric Cable 2AWG 4AWG 6AWG 10AWG 16AWGUS$ 1 - 10MOQ: 1 Meter
-
UL Listed Photovoltaic Cable 2KV Solar PV CableUS$ 0.1 - 10MOQ: 1 Meter
Construction:
ITEM |
Unit |
Spec.Value |
|
Conductor |
Material |
-- |
Tinned Copper |
Construction |
NO./mm |
84/0.30±0.004 |
|
Dia.(Approx) |
mm |
3.5 |
|
Insulation |
Material |
-- |
XLPO |
Thickness |
mm |
0.8 |
|
Dia.(Approx) |
mm |
5.1 |
|
Sheath |
Material |
-- |
XLPO |
Thickness |
mm |
0.8 |
|
Dia.(Approx) |
mm |
7.1 |
|
Color |
-- |
Red&Black |
|
Weight |
kg/km |
110 |
|
Characteristics:
Rated Voltage |
AC 0.6/1kV;DC 1.8kV |
Ambient Temperature |
-40~90℃ |
Max. Temperature at Conductor |
120℃ |
Max. Conductor Resistance at 20℃ |
3.39Ω/km |
Th permitted short-circuit-temperature(5s) |
200℃ |
Weathering/UV resistance |
PASS |
Flame Test |
IEC 60332-1 |
Rated Current |
70A |
We would like to introduce ourselves as an ISO9001/14001/18001 ,CCC ,UL certificated Manufacturer of different kinds of Cables ,our products have exported to more than 50 countries .
Henan Huaxing Cables and Wires Company .Ltd ,was found in 1984 and expanded in 2005, the workshop covers an area of 67,000m2, building area is about 28,000m2,,more than 260 employees , We serve under the skillful & experienced management which provide effective & efficient service to you.
We are also the Long term supplier of Ministry of Electric power of Yemen ,National Electric Energy Agency of Italy ,Electric power company of France, numbers of listed companies already established long business relationship with us .
Our hot products including Aluminum Rod ,All Aluminum Conductor( AAC),All Aluminum Alloy Conductor (AAAC),Aluminum Conductor Steel Reinforced(ASCR), Aerial Cable, Concentric Cable ,Power Cable ,PV Cable ,Electric Wire and so on;
