UL Type PV USE-2 Sunguard XLPE Photovoltaic Wire 600V
US$ 500 - 500
MOQ: 1000 Kilometers
Key Specifications
Get Latest Price
Brand Name:
SHUANG JIA
Place of Origin:
Henan, China
Model Number:
USE-2
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
RHH/RHW/RHW-2/USE-2 Solar Cable PV Cable 6awgUS$ 0.36 - 0.36MOQ: 5 Kilometers -
Aluminum RodUS$ 0.5 - 3.5MOQ: 1 Meter
-
Solar PV Wire (Photovoltaic Wire/ UL 4703)US$ 0.1 - 2.2MOQ: 1000 Meters
-
10awg Solar Panel Cable,6mm2 Solar Photovoltaic WireUS$ 0.1 - 2.5MOQ: 1000 Meters
-
High Quality 4mm2 dc Solar CableUS$ 0.1 - 3.5MOQ: 1000 Meters
Brand Name
SHUANG JIA
Place of Origin
Henan, China
Model Number
USE-2
Type
Insulated
Conductor Material
Aluminum
Conductor Type
Stranded
| Photovoltaic(PV)Cable AL Conductor | ||||||||
| Cross-linked Polyethylene Insulated 2kv UL Type PV/RHH or RHH-2 or 600V USE-2 or c(UL)RWU90 1kv -40°C to 90°C Wet/105°C Dry | ||||||||
| Applications | ||||||||
| Single conductor,sunlight-resistand,photovoltaic wire reted 90°C wet or 105 °C dry 2000V for interconnection wiring of grounded and ungrounded photovoltaic power systems as described in Section 690.31(A)and other applicable parts of the National Eletrical Code (NEC),NFPA 70 | ||||||||
| Construction | ||||||||
| Conductor:6 AWG thru 1000 kcmil compact aluminum ACM (8000series) | ||||||||
| Insulation:Flame-retardant Cross-Linked Polyethylene (XLPE),black | ||||||||
| Print:AWG 2000V PV WIRE OR RHH OR RHW-2 OR 600V USE-2(SIZE) AL ACM 90 °C WET OR 105°C DRY SUN RES(UL) -40°C VW-1 c(UL) RWU90 1000V DIR BUR MONTH/YEAR OF MFG SEQUENTIAL FOOTAGE MARK | ||||||||
| Options:Colors available on request | ||||||||
| Features | ||||||||
| •Rated 90°C wet and 105 °C dry | ||||||||
| •Deformation-resistant at high temperatures | ||||||||
| •Excellent moisture resistance | ||||||||
| •Excellent resistance to crush and compression cuts | ||||||||
| •Resistant to most oils and chemicals | ||||||||
| •UV/sunlight-resistant | ||||||||
| •Meets cold bend test at -40°C | ||||||||
| Compliances | ||||||||
| •UL 4703 Type PV | ||||||||
| •ICEA S-95-658/NEMA WC70 | ||||||||
| •UL 44 Type RHH or RHW-2 | ||||||||
| •UL 845 Type USE-2 | ||||||||
| •c(UL) RWU90 1KV | ||||||||
| •UL 1581 VW-1 | ||||||||
| •IEEE 383 for sizes 1/0 AWG and larger | ||||||||
| Packaging | ||||||||
| Material cut to length and shipped on non-returnable wood reels | ||||||||
| Item# | Conductor Size (AWG/kcmil) | Conductor Stranding | Conductor Diameter(in) | Insulation Thickness(in) | Cable Diameter(in) | Aluminum Weight/MFT(lb) | Net Cable Weight/MFT(lb) | Nominal DC Resistance (Ohms/MFT at 20°C) |
| PVA-2000-6 | 6 | 7 | 0.169 | 85 | 0.339 | 25 | 62 | 0.661 |
| PVA-2000-4 | 4 | 7 | 0.213 | 85 | 0.383 | 39 | 83 | 0.415 |
| PVA-2000-2 | 2 | 7 | 0.268 | 85 | 0.438 | 63 | 114 | 0.216 |
| PVA-2000-1 | 1 | 18 | 0.299 | 105 | 0.509 | 79 | 155 | 0.207 |
| PVA-2000-1/0 | 1/0 | 18 | 0.336 | 105 | 0.546 | 99 | 183 | 0.164 |
| PVA-2000-2/0 | 2/0 | 18 | 0.376 | 105 | 0.586 | 125 | 218 | 0.130 |
| PVA-2000-3/0 | 3/0 | 18 | 0.423 | 105 | 0.633 | 158 | 260 | 0.103 |
| PVA-2000-4/0 | 4/0 | 18 | 0.475 | 105 | 0.685 | 199 | 313 | 0.082 |
| PVA-2000-250 | 250 | 35 | 0.520 | 120 | 0.760 | 235 | 376 | 0.069 |
| PVA-2000-300 | 300 | 35 | 0.570 | 120 | 0.810 | 282 | 435 | 0.058 |
| PVA-2000-350 | 350 | 35 | 0.616 | 120 | 0.856 | 329 | 494 | 0.050 |
| PVA-2000-400 | 400 | 35 | 0.659 | 120 | 0.899 | 376 | 538 | 0.043 |
| PVA-2000-500 | 500 | 35 | 0.736 | 120 | 0.976 | 471 | 649 | 0.035 |
| PVA-2000-600 | 600 | 58 | 0.813 | 135 | 1.083 | 565 | 786 | 0.029 |
| PVA-2000-700 | 700 | 58 | 0.877 | 135 | 1.147 | 659 | 895 | 0.025 |
| PVA-2000-750 | 750 | 58 | 0.908 | 135 | 1.178 | 706 | 950 | 0.023 |
| PVA-2000-900 | 900 | 58 | 0.999 | 135 | 1.269 | 847 | 1114 | 0.019 |
| PVA-2000-1000 | 1000 | 58 | 1.060 | 135 | 1.330 | 941 | 1223 | 0.017 |
