Underground Heavy Duty Cables Steel Wire Armoured Cable SWA Cable
US$ 0.1 - 10
MOQ: 1000 Meters
Key Specifications
Get Latest Price
Brand Name:
shuangjia
Place of Origin:
Henan, China
Model Number:
VV VLV YJV YJLV
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CU Power CableUS$ 1 - 25MOQ: 1000 Meters -
XPLE Insulated Power Cable 150mm2 LVUS$ 0.36 - 50.32MOQ: 1000 Kilometers
-
8030 Aluminum Alloy CableUS$ 1.5 - 4.9MOQ: 1000 Meters
-
8030 Aluminum Alloy CableUS$ 1.5 - 4.9MOQ: 1000 Meters
-
XLPE Insulated Steel Tape Armoured Power Cable (10KV 3-150)US$ 0.2 - 2.4MOQ: 1000 Meters
Brand Name
shuangjia
Place of Origin
Henan, China
Model Number
VV VLV YJV YJLV
Type
Low Voltage
Application
Underground
Insulation Material
XLPE
Jacket
PVC
Conductor Material
Aluminum
Steel Wire Armoured Cable Al/XLPE/SWA/PVC NA2XRY 3X95mm2 11KV
I Features
a. Nominal cross section: 1~400mm2
b. 1~6 core/ cores
c. copper/aluminium conductor
d voltage class: 1KV upto 35KV
II Production standard:
The product is manufactured according to GB/T12706-2008, and upon request.
This product is suitable for use in power distribution lines or fixed installation with rated power-frequency voltage up to and including 0.6/1KV.
And the main characteristic of low smoke and nonhalogen fire resistant cable are hard to catch fire and the expansion of fire is limited in a area, applicable for the places where cable wiring is densesuch as power plant, metro, tunnel, high-rise building, large- scale factories, oil feild or coal mine,etc.
Fireretardant cable can operate normally for some time when it is burning.
A) Rated power-frequency voltage UO/U 0.6/1KV
B) MAX. permissible continuous operating temperature of conductor:70°C
C) MAX. conductor temperature is lower than160 °C when cable is shorted for less than 5 seconds.
D) The ambient temperature when installing should not below 0°C
E) Bending radius of cable should not be less than 10 times of diameter of the cable.
III Application
| Specification mm2 | O.D mm | Reference weight of cable kg/km | Recommended Current Capacity (A) | Max D.C resistance at20°C (Ω/km) | |||
| copper | aluminium | copper | aluminium | copper | aluminium | ||
| 1×10 | 12.0 | 280 | 223 | 72 | 55 | 1.83 | 3.08 |
| 1×16 | 13.0 | 354 | 263 | 96 | 73 | 1.15 | 1.91 |
| 1×25 | 14.4 | 454 | 323 | 124 | 96 | 0.727 | 1.20 |
| 1×35 | 15.1 | 551 | 366 | 152 | 137 | 0.524 | 0.868 |
| 1×50 | 17.0 | 717 | 452 | 193 | 152 | 0.387 | 0.641 |
| 1×70 | 18.5 | 909 | 541 | 240 | 184 | 0.268 | 0.443 |
| 1×95 | 20.4 | 1164 | 658 | 290 | 220 | 0.193 | 0.320 |
| 1×120 | 21.9 | 1396 | 757 | 336 | 258 | 0.153 | 0.253 |
| 1×150 | 23.8 | 1692 | 895 | 386 | 300 | 0.124 | 0.206 |
| 1×185 | 25.6 | 2026 | 1044 | 442 | 346 | 0.0991 | 0.164 |
| 1×240 | 29.1 | 2583 | 1309 | 534 | 414 | 0.0754 | 0.125 |
| 1×300 | 32.1 | 3277 | 1657 | 608 | 470 | 0.0601 | 0.100 |
| 1×400 | 36.4 | 4203 | 2096 | 723 | 557 | 0.047 | 0.0778 |
| 2×1.5 | 12.0 | 235 | -- | 17 | -- | 12.1 | -- |
| 2×2.5 | 12.8 | 276 | 246 | 23 | 18 | 7.41 | 12.1 |
| 2×4 | 14.6 | 355 | 308 | 32 | 25 | 4.61 | 7.41 |
| 2×6 | 15.6 | 422 | 351 | 41 | 32 | 3.08 | 4.61 |
| 2×10 | 17.9 | 546 | 431 | 58 | 45 | 1.83 | 3.08 |
| 2×16 | 19.9 | 706 | 521 | 79 | 60 | 1.15 | 1.91 |
| 2×25 | 22.7 | 918 | 653 | 106 | 80 | 0.727 | 1.20 |
| 2×35 | 24.2 | 1131 | 760 | 124 | 96 | 0.524 | 0.868 |
| 2×50 | 23.0 | 1295 | 773 | 156 | 120 | 0.387 | 0.641 |
| 2×70 | 26.6 | 1779 | 1048 | 188 | 147 | 0.268 | 0.443 |
| 2×95 | 29.3 | 2312 | 1307 | 206 | 156 | 0.193 | 0.320 |
| 2×120 | 30.7 | 2765 | 1496 | 239 | 183 | 0.153 | 0.253 |
| 2×150 | 33.7 | 3375 | 1789 | 282 | 213 | 0.124 | 0.206 |
| 2×185 | 36.7 | 4085 | 2128 | 314 | 246 | 0.0991 | 0.164 |
| 2×240 | 40.1 | 5182 | 2614 | 379 | 294 | 0.0754 | 0.125 |
| 2×300 | 43.9 | 6416 | 3153 | 432 | 334 | 0.0601 | 0.100 |
| 3×1.5 | 12.5 | 262 | -- | 15 | -- | 12.1 | -- |
| 3×2.5 | 13.3 | 314 | 270 | 19 | 15 | 7.41 | 12.1 |
| 3×4 | 15.2 | 416 | 345 | 27 | 21 | 4.61 | 7.41 |
| 3×6 | 16.3 | 505 | 397 | 34 | 27 | 3.08 | 4.61 |
| 3×10 | 18.8 | 669 | 495 | 49 | 39 | 1.83 | 3.08 |
| 3×16 | 21.0 | 883 | 607 | 66 | 52 | 1.15 | 1.91 |
| 3×25 | 24.0 | 1171 | 774 | 88 | 69 | 0.727 | 1.20 |
| 3×35 | 25.6 | 1464 | 907 | 106 | 82 | 0.524 | 0.868 |
| 3×50 | 25.3 | 1873 | 1089 | 133 | 106 | 0.387 | 0.641 |
| 3×70 | 28.6 | 2446 | 1348 | 166 | 128 | 0.268 | 0.443 |
| 3×95 | 31.7 | 3230 | 1723 | 202 | 156 | 0.193 | 0.320 |
| 3×120 | 33.2 | 3892 | 1989 | 234 | 180 | 0.153 | 0.253 |
| 3×150 | 36.7 | 4788 | 2409 | 272 | 212 | 0.124 | 0.206 |
| 3×185 | 39.8 | 5796 | 2861 | 303 | 244 | 0.0991 | 0.164 |
| 3×240 | 43.7 | 7411 | 3559 | 368 | 290 | 0.0754 | 0.125 |
| 3×300 | 47.9 | 9212 | 4317 | 414 | 322 | 0.0601 | 0.100 |
IV Production Range
| Type | Name | Nominalcross-section(mm2) | Number of cores |
| VV/VLV (0.6/1KV) | Copper/aluminium core PVC insulated PVC sheathed power cable(0.6/1KV) | 1.5/2.5 - 400 | 1,2,3,4,5,6 |
| VV22/VLV22 (0.6/1KV) | Copper/aluminium core PVC insulated steel tape armored PVC sheathed power cable(0.6/1KV) | 1.5/2.5 - 400 | 1,2,3,4,5,6 |
| YJV/YJLV (0.6/1kv) | 1.5 - 400 | 1,2,3,4,5,6 | |
| YJV22/YJLV22 (0.6/1kv) | Copper/aluminium core XLPE insulated steel tape armored PVC sheathed power cable(0.6/1KV) | 1.5 - 400 | 1,2,3,4,5,6 |
| ZR-VV/ZR-VLV (0.6/1KV) | Copper/aluminium core PVC insulated PVC sheathed power cable with flame-retardant(0.6/1KV) | 1.5 - 400 | 1,2,3,4,5,6 |
| ZR-VV22/ZR-VLV22 (0.6/1KV) | Copper/aluminium core PVC insulated steel tape armored PVC sheathed power cable with flame-retardant(0.6/1KV) | 1.5 - 400 | 1,2,3,4,5,6 |
| ZR-YJV/ZR-YJLV (0.6/1kv) | Copper/aluminium core XLPE insulated PVC sheathed power cable with flame-retardant (0.6/1kv) | 1.5 - 400 | 1,2,3,4,5,6 |
| ZR-YJV22/ZR-YJLV22 (0.6/1kv) | Copper /aluminium core XLPE insulated steel tape armored PVC sheathed power cable with flame-retardant (0.6/1KV) | 1.5 - 400 | 1,2,3,4,5,6 |
| NH-VV 0.6/1KV | Copper core PVC insulated PVC sheathed power cable with fire-resistance (0.6/1KV) | 1.5 - 400 | 1,2,3,4,5,6 |
| NH-VV22 0.6/1KV | Copper core PVC insulated steel tape armored PVC sheathed power cable with fire-resistance (0.6/1KV) | 1.5 - 400 | 1,2,3,4,5,6 |
| NH-YJV 0.6/1KV | Copper core XLPE insulated power cable with fire-resistance | 1.5 -400 | 1,2,3,4,5,6 |
| NH-YJV22 0.6/1KV | Copper core XLPE insulated steel tape armored power cable with fire-resistance | 1.5 -400 | 1,2,3,4,5,6 |
| WDZ-YJE 0.6/1KV | Copper core XLPE insulated low smoke non- halogen flame retardant power cable | 1.5 -400 | 1,2,3,4,5,6 |
| WDZN-YJE0.6/1KV | Copper core XLPE insulated low smoke non- halogen flame- retardant power cable with fire-resistence | 1.5 -400 | 1 |
V CERTIFICATE
