Aluminum 8000 Series Concentric Cable 600/1000V
1.APPLICATION
Used in service entrances replacing low voltage bundled cables. Also suitable for sub main distribution and particularly used within high-rise buildings and street lighting systems. These cables offer high resistance to aging, abrasion, moisture, chemicals, oils and acids and afford protection of phase conductors against external ingress.
2.CONSTRUCTION
Conductor: stranded aluminum alloy AA8000 class B according to ASTM B 231 and UL 854
Insulation: XLPE (Cross-Linked Polyethylene)
Concentric Conductor: Single layer of aluminum wires AA8000 served as the neutral conductor, equal to the equivalent AWG size of the power conductor
Sheath:PVC jacket extruded
3.CHARACTERISTICS
Voltage Rating (U0/U): 600/1000V
Temperature Rating: -40C to +90C
4.Compliance:
ASTM B8
ASTM B193
UL 44
UL 854
BS 7870
IEC 60502
