AAC/AAAC/ACSR/XLPE or PVC Aerial Bunded Cable 25mm 35mm 50mm 70mm ABC Cable

AAC/AAAC/ACSR/XLPE or PVC Aerial Bunded Cable 25mm 35mm 50mm 70mm ABC Cable thumbnail-1
AAC/AAAC/ACSR/XLPE or PVC Aerial Bunded Cable 25mm 35mm 50mm 70mm ABC Cable thumbnail-2
AAC/AAAC/ACSR/XLPE or PVC Aerial Bunded Cable 25mm 35mm 50mm 70mm ABC Cable thumbnail-3
AAC/AAAC/ACSR/XLPE or PVC Aerial Bunded Cable 25mm 35mm 50mm 70mm ABC Cable photo-1
AAC/AAAC/ACSR/XLPE or PVC Aerial Bunded Cable 25mm 35mm 50mm 70mm ABC Cable photo-2
AAC/AAAC/ACSR/XLPE or PVC Aerial Bunded Cable 25mm 35mm 50mm 70mm ABC Cable photo-3
US$ 1 - 10 MOQ: 1 Meter
Key Specifications
Get Latest Price
Brand Name:
shuangjia
Place of Origin:
Henan, China
Model Number:
ABC
Contact Supplier Request Quote Chat Now
Henan Huaxing Wires And Cables Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name shuangjia
Place of Origin Henan, China
Model Number ABC
Type Low Voltage
Application Overhead
Jacket PVC
Conductor Material Aluminum

Specifications

-IEC ASTM DIN BS standard
-ISO CCC certificate
-Factory direct sale
-Prompt delivery
-30 years production experience

Duplex Service Drop
1Application
Primarily used for 120volt overhead service application such as street lighting,outdoor lighting,and temporary service for construction.To be used at voltages of 600 volts phase-to-phase or less and at conductor temperatures not to exceed 75 for polyethylene insulated conductors or 90 for crosslinked polyethylene(XLP) insulated conductors.
2Construction

Code*Word Phase conductor Bare Neutral Message Nominal lay Length Weight Per
1000 ft.(lbs.)		 Allo wable Amp acitles
Size
(A WG)		 Stranding Insul
Thick(Mils)		 Size
(AWG)		 Stranding Rated
Strength
(lbs.)		 inches XLP POLY XLP POLY
AAC Neutral-messenger
Pekingese 6 1 45 6 7 563 10.36 61 61 85 70
Collie 6 7 45 6 7 563 10.36 64 64 85 70
Dachshund 4 1 45 4 7 881 10.36 92 92 115 90
Spaniel 4 7 45 4 7 881 10.36 96 96 115 90
Doberman 2 7 45 2 7 1350 14.88 147 147 150 120
Malemute 1/0 9 60 1/0 7 1990 14.88 234 234 205 160

Triplex Service Drop
1Application
Used to supply power,usually from a pole-mounted transformer,to the user's service head where connection to the service entrance cable is made.To be used at voltage of 600 volts phase-to-phase or less and at conductor temperature not to exceed 75 for polyethylene insulated conductors or 90 for crosslinked polyethylene(XLP) insulated conductors.
2Construction

Code*Word Phase conductor Bare Neutral Message Nominal lay Length Weight Per
1000 ft.(lbs.)		 Allo wable Amp acitles
Size
(A WG)		 Stranding Insul
Thick(Mils)		 Size
(AWG)		 Stranding Rated
Strength
(lbs.)		 inches XLP POLY XLP POLY
AAC Neutral-messenger
Pateela 6 7 45 6 7 563 14.88 103 103 85 70
Oyster 4 7 45 4 7 881 14.88 154 154 115 90
Clam 2 7 45 2 7 1350 20.58 233 233 150 120
Murex 1/0 7 60 1/0 7 1990 20.58 374 374 205 160
Purpura 1/0 9 60 1/0 7 1990 20.58 368 368 205 160
Nassa 2/0 7 60 2/0 7 2510 25.42 462 462 235 185
Melita 3/0 17 60 3/0 19 3310 29.97 562 562 275 215
Portunus 4/0 18 60 4/0 19 4020 29.97 696 696 315 245
Nannynose 336.4 19 60 336.4 19 6146 38.79 1118 1118 420 325


Quadruplex Service Drop
1Application
Used to supply 3-phase power,usually from a pole-mounted transformer,to the user's service head where connection to the service entrance cable is made.To be used at voltage of 600 volts phase-to-phase or less and at conductor temperature not to exceed 75 for polyethylene insulated conductors or 90 for crosslinked polyethylene(XLP) insulated conductors.
2Construction

Code*Word Phase conductor Bare Neutral Message Nominal lay Length Weight Per
1000 ft.(lbs.)		 Allo wable Amp acitles
Size
(A WG)		 Stranding Insul
Thick(Mils)		 Size
(AWG)		 Stranding Rated
Strength
(lbs.)		 inches XLP POLY XLP POLY
AAC Neutral-messenger
Clydessdale 4 1 45 4 7 881 20.58 198 198 100 80
Pinto 4 7 45 4 7 881 20.58 211 211 100 80
Mustang 2 7 45 2 7 1350 25.42 318 318 135 105
Criollo 1/0 9 60 1/0 7 1990 25.42 503 503 180 140
Percheron 2/0 11 60 2/0 7 2510 29.97 619 619 205 160
Hanovarian 3/0 17 60 3/0 19 3310 35.18 764 764 235 185
Oldenburg 4/0 18 60 4/0 19 4020 35.18 945 945 275 210
Lippizaner 336.4 19 80 336.4 19 6146 38.79 1519 1519 370 280


 AAC/AAAC/ACSR/XLPE or PVC Aerial Bunded Cable 25mm 35mm 50mm 70mm ABC cable

AAC/AAAC/ACSR/XLPE or PVC Aerial Bunded Cable 25mm 35mm 50mm 70mm ABC cableAAC/AAAC/ACSR/XLPE or PVC Aerial Bunded Cable 25mm 35mm 50mm 70mm ABC cable

AAC/AAAC/ACSR/XLPE or PVC Aerial Bunded Cable 25mm 35mm 50mm 70mm ABC cableAAC/AAAC/ACSR/XLPE or PVC Aerial Bunded Cable 25mm 35mm 50mm 70mm ABC cable
