Help CenterThin PVC Insulated Copper Wire Cheap Electrical Wires
Related Products
-
Thin PVC Insulated Copper Wire Cheap Electrical WiresUS$ 1 - 10MOQ: 1 Meter -
Electric Aluminum RodUS$ 1 - 5MOQ: 1 Meter
-
Aac(all Aluminum Conductor) Acsr Dog Conductor PriceUS$ 1.5 - 5.5MOQ: 1 Meter
-
High Pure Aluminum and Aluminum AlloyUS$ 0.1 - 3MOQ: 1 Meter
-
ACSR Conductor Specifications Aluminum Conductor, Steel ReinforcedUS$ 0.1 - 2.7MOQ: 1 Meter
Description of electrical power cable :
1. Twin core PVC insulated
2. AC 450/750V
3. 0.75-240mm²
4. rated temperature: 65~75°C
5. Design and manufacture according to the requirements of customers.
Application of electrical power cable :
The products is suitable for use in power installations, fixed wiring or flexible connections for electrical appliances like lighting, electronic equipment, instrument and communication equipment with rated voltage 450/750V, 300/350V, 300/300V
Packing of electrical power cable :
shrink wrapping/rolls/ carton box / plastic spool /wood spool and any others per the customer's request
Delivery time of electrical power cable :
20days more or less after confirm t/t payment
Advantage of our factory:
1. More than 10 years of producing many kinds of electric wires and cables
2. Conductor can be used pure copper wrie or CCA cheap conductor.
3. competitive price & good service.
4. OEM are welcome. We can also produce standard or non-standard wires and cables.
Detailed parameters
Model |
Name |
BV |
Copper core PVC insulated electric wire |
BLV |
Aluminum core PVC insulated electric wire |
BVR |
Copper core PVC insulated flexible electric wire |
BVV |
Copper core PVC insulated PVC sheathed round electric wire |
BVVB |
Copper core PVC insulated PVC sheathed parallel electric wire |
BLVVB |
Aluminum core PVC insulated PVC sheath PARALLEL electric wire |
| Nominal sectional area mm2 |
Conductor No/Dia. mm |
Nominal Insulated thick mm |
Max overall Dia. mm |
Condcutor Resistance at 20 |
Min insulated resistance at 70MΩ/km |
Weight Kg/km |
| 2.5 | 9/0.41 | 0.8 | 4.2 | 7.41 | 0.011 | 33.0 |
| 4 | 19/0.52 | 0.8 | 4.8 | 4.61 | 0.009 | 48.0 |
| 6 | 19/0.64 | 0.8 | 5.6 | 3.08 | 0.0084 | 68.0 |
| 10 | 49/0.52 | 1.0 | 7.6 | 1.83 | 0.0072 | 115.0 |
| 16 | 49/0.64 | 1.0 | 8.8 | 1.15 | 0.0062 | 176.0 |
| 25 | 98/0.58 | 1.2 | 11.0 | 0.727 | 0.0058 | 272.0 |
| 35 | 133/0.58 | 1.2 | 12.5 | 0.524 | 0.0052 | 384.0 |
| 50 | 133/0.68 | 1.4 | 16.5 | 0.387 | 0.0051 | 510.0 |
| 70 | 189/0.68 | 1.4 | 16.5 | 0.268 | 0.0045 | 714.0 |
| 95 | 259/0.68 | 1. | 19.5 | 0.139 | 0.0035 | 965.0 |
| 120 | 259/0.76 | 1.8 | 22.0 | 0.153 | 0.0032 | 1210.0 |
| 150 | 259/0.85 | 1.8 | 25.0 | 0.124 | 0.0032 | 1510.0 |
Flexible wire
