2W Under Water Solenoid Valve /Gas Diesel Oil Normal Closed / 2W200-20 Direct Brass Solenoid Valve
- Ningbo or Shanghai
- T/T Credit Card
You May Like
-
Direct Acting 2 Way 2W025-08 Solenoid Valve/ Water,air,gas,oil/ 1/4"/Pneumatic Solenoid Valve
-
2W400-40 1-1/2" Explosion Proof Solenoid Valve, Ex mb I/II T4 Class
-
VX2120-08 (1/4") 2/2 Way Electric Control Solenoid Valve
-
PU225-1"-AC110V Diaphragm Solenoid Valves to Control Air, Water
-
KLQD Brand 2/2 Way 1/2 Inch Air Water 24V Stainless Steel Material Solenoid Valve
-
KLMQ Cut off Gas Solenoid Valve
Product Details
| Brand Name | KLQD | Place of Origin | Zhejiang, China | |
| Model Number | 2w200-20 | Material | Brass | |
| Structure | Control | Standard or Nonstandard | Standard | |
| Pressure | Medium Pressure | Power | Solenoid | |
| Port Size | 1/2" | Media | Water | |
| Temperature of Media | Medium Temperature |
Product Description
Specification
Model | 2W200-20 |
Working Medium | Air,Water,Oil,Gas |
Motion Pattern | Direct Drive Type |
Type | Normal Close Type |
Aperture of Flow Rate | 20 |
CV Value | 4.8 |
Joint Pipe Bore | G3/4" |
Operation Fluid Viscosity | 20CST Below |
Working-pressure | Air:0~0.7Mpa; Water,Oil:0~0.5Mpa |
Max Pressure Resistance | 1.0MPa |
Operating Temperture | -5~80°C |
Voltage Range | -10%~+10% |
Material of Body | Brass |
Material of Oil Seal | NBR,EPDM or VITON |
TYPE | 2W-025-06 | 2W-025-08 | 2W-040-08 | 2W-040-10 | 2W-160-10 | 2W-160-15 | 2W-200-20 | 2W-250-25 | 2W-350-35 | 2W-400-40 | 2W-500-50 |
THEAD G | 1/8" 1/4" | 1/8" 1/4" | 1/4" | 3/8" | 3/8" | 1/2" | 3/4" | 1" | 1 1/4" | 1 1/2" | 2" |
Aperture of flow rate mm | 2.5 | 2.5 | 4 | 4 | 16 | 16 | 20 | 25 | 35 | 40 | 50 |
Motion Pattern | direct dirve |
|
|
|
|
|
|
|
|
|
|
Cv | 0.23 | 0.23 | 0.6 | 0.6 | 4.8 | 4.8 | 7.6 | 12 | 24 | 29 | 48 |
length mm | 40.5 | 40.5 | 40.5 | 52.5 | 69 | 69 | 73 | 99 | 115 | 120 | 154 |
height mm | 75 | 75 | 75 | 90 | 117 | 117 | 123.5 | 134.5 | 154 | 162 | 185 |
