Single Coil Alloy Material 3v210-08 Pneumatic Solenoid Valve
- T/T Credit Card
You May Like
-
5/3 Way Alloy Material Double Coil Solenoid Valve 4V320-08
-
Low Cost,Namur Solenoid Valve
-
5 Port 2 Position Internal Pilot Alloy Material Pneumatic Electrical Valve Model 4V310-10
-
1/2 Inch Stainless Steel Solenoid Valve Water KLQD Brand 2WB-15 Model
-
5 Port 2 Position Internal Pilot Air Solenoid Valve Model 4V210-08
-
3 Way Solenoid Valve ,VX31/32/33 Series 3/2 Way Solenoid Valve
Product Details
| Brand Name | KLQD brand 3v210-08 pneumatic solenoid valve | Place of Origin | Zhejiang, China | |
| Model Number | 3v210-08 pneumatic solenoid valve | Material | Alloy | |
| Application | General | Structure | Control | |
| Standard or Nonstandard | Standard | Pressure | Medium Pressure | |
| Power | Solenoid | Port Size | 1/4 | |
| Temperature of Media | Medium Temperature |
Product Description
5/3 way alloy material double coil solenoid valve 4V320-08
1,5/3 way double coil solenoid valve
2,Type: 100 series
3,Port size: 1/8"
4. Model 3v210-08 pneumatic solenoid valve
Just feel free to contact with me for cheaper price.
Skype: CaoxL090
Model | 4V210-06 | 4V220-06 | 4V230C-06 | 4V230E-06 | 4V230P-06 | 4V210-08 | 4V220-08 | 4V230C-08 | 4V230E-08 | 4V230P-08 |
| 4A210-06 | 4A220-06 | 4A230C-06 | 4A230E-06 | 4A230P-06 | 4A210-08 | 4A220-08 | 4A230C-08 | 4A230E-08 | 4A230P-08 |
Valve type | 5/2 way | 5/3 way | 5/2 way | 5/3 way | ||||||
Effectiive area | 14 mm2(CV=0.78) | 12 mm2(CV=0.67) | 16 mm2(CV=0.89) | 12 mm2(CV=0.67) | ||||||
Model | 3V210-06 | 3V220-06 | 3A210-06 | 3A220-06 | 3V210-08 | 3V220-08 | 3A210-08 | 3A220-08 | ||
Valve type | 3/2 way | |||||||||
Effective area | 14 mm2(CV=0.78) | 16 mm2(CV=0.89) | ||||||||
Port size | Inlet , outlet,exhaust port=1/8" | Inlet, outlet=1/4", Exhaust port=1/8" | ||||||||
Working medium | 40 micron filtered air | |||||||||
Operation | Internal piloted 3v210-08 pneumatic solenoid valve | |||||||||
Working pressure | 0.15-0.8 Mpa | |||||||||
Max. pressure | 1.2 Mpa | |||||||||
Temperature | 5-50 degrees centigrade | |||||||||
Voltage tolerance | Plus or minus 10% | |||||||||
Power consumption | AC:5.5 VA, DC:4.8W | |||||||||
Connector protection | F Class, IP65 | |||||||||
Wiring/Connector | Cable/Lead wire or DIN connector | |||||||||
Frequency | 5 cycles/ sec | |||||||||
Response time | 0.05 sec | |||||||||
